Schlage (von Duprin) Ps902 4rfa Power Supply Brand New & Sealed!

US $490

Branchville, New Jersey, United States
Jun 7th

Open on mobile:
QR code

Schlage Electronics PS902 2-Amp Class 2 Power Supply with 4-Relay Output Board and Fire Alarm Interface Board, 12/24 VDC Output - Brand New in Box - Outside of box just has a few stains but item is brand new with no damage at all. -Overview and specs below If you have any questions or concerns please feel free to message me at anytime and I will get back to you as soon as possible. Overview The Schlage comprehensive line of power supplies and option boards was designed to address the changing needs of the access control market. Installation is simplified by utilizing a flat mounting design and polarized locking connectors for option boards. This design eliminates the need for racks and side connectors. The flat mounting of the option boards also provides for easier access to the terminal blocks for connection of electrified devices (such as electrified strikes, electromagnetic locks, card readers, etc.). Common to the line of PS900 Series power supplies is a constant output rating at both 12v and 24v settings, universal 120 VAC to 240 VAC input, and polarized option board connectors. New re-alarm interface board mounting allows outputs to be configured as switched (power cut) or unswitched (power continues) when signal is provided. Features and Benefits - 2A @ 12/24 VDC constant output, field selectable with jumper - Provides low-voltage, Class 2, filtered and regulated power - Universal 120-240 VAC, fused primary input - Single polarized option board connector - AC input and DC output monitoring circuit with LED indicators - Externally visible AC input indicator with isolated SPDT contacts - High-voltage protective cover for AC circuitry - Battery back-up board auto-selects voltage - Optional Fire Alarm plug-in board available - UL 294, ULC-S318, RoHS, and FCC Part 15 certified Options - Emergency Interface/Fire Alarm Relay (FA) - Key lock available for added security (KL) - Battery backup - 2 relay QEL and EL panic device control board - 4 relay option board - 4 relay option board with logic - Field configurable for: • Time delay function • Auto operator • Security interlock - Fused, 8 zone option board - PTC, 8 zone option board PS902 Power Supply Specifications Specification Description Inpult Voltage 120/240 VAC, 50/60 Hz, universal input. Output Voltage 2A @ 12 or 24 VDC. Field selectable with jumper. Switching supply, 5% regulation, 240mVpp max ripple. Enclosure Grey/baked enamel. 14"(H)x12"(W)x4"(D). Eight 1/2" x 3/4" knockouts. NEMA Grade 1. Hinged cover with lock down screws. Operating 32° - 120°F Temperature (0° - 49°C). Certifications ANSI/UL 294 ULC-S318 RoHS FCC Part 15 Class 2 Available Option Boards 900-BB: Battery backup board only. 900-BBK: Battery backup kit (backup board plus battery pack). 900-FA: Plug-in re alarm (installed on main board). 900-2RS: 2 Relay EL panic device control board. 900-4R: 4 Relay output board. 900-4RL: 4 Relay board with integrated logic for controlling security interlocks, auto operators, and time delay function. 900-8F: Fused, 8 zone option board. 900-8P: PTC, 8 zone option board. AC Primary 3.15A, 250v, 5 x 20mm Fuse Size SLOW BLOW. Battery Fuse 7.15A 32v ATO blade Size style. DC Output Overload protection - Protection current limited foldback circuit. Indicators LED indicators: • AC input (visible on outside of enclosure) • DC output. Isolated SPDT contacts v to monitor AC power status. Weight (Power Approx. 9.0 lbs Supply) Weight (Each 2.4 lbs Battery) AC Input 3 position terminal block Termination with protective cover. Wire capacity: 10 AWG max. DC Output 2 position terminal block Termination. Wire capacity: 12 AWG max. Option Board 1 Connectors Fire Alarm Yes Board Connector Keylock Optional Accessories 900-BAT : Backup battery pack
