Schmitt32 Mini Line Drilling System

US $16000

Birnamwood, Wisconsin, United States
Jun 2nd

Open on mobile:
QR code

Please visit SCHMITT32.com for product details, videos and contact information. The SCHMITT32 MINI line drill system quickly and accurately locates and drills all the 5mm holes necessary for the precise installation of concealed Euro style hinges, drawer slides, (side mount or undermount type), and shelf support pins. The system is a natural for modern frameless style cabinets with narrow gaps between doors and drawer fronts and for the wider reveal 1/2 overlay style. The MINI even works on certain face frame cabinet configurations. The SCHMITT32 MINI uses a plunge router with a 5mm brad point carbide tipped drill bit and an adapterr bushing to fit the 1/2 inch chuck. The fixture with its front alignment fence and end stops locates cabinet panels. The plunge router with base attachment pressed against the repositionable guide rail, and its ratchet pawls engaged with the numbered notches, can accurately drill clean precise holes located in a square 32mm grid pattern starting at 37mm (industry standard) from the front edge of a panel and 64mm down from the top edge covering a maximum panel size of about 30 x 40 inches. this entire grid pattern or any one hole or row of holes can be moved any where over the surface of the panel by use of shop made spacer blocks placed between front fence or the end stops. Usually most of the possible hole locations are not needed. You drill only those holes needed for hinge placement, drawer hardware placement and alignment, and adjustable shelves. The router base allows a small front to back adjustment of the columns of holes so that the placement of hinge plates and drawer slides can be moved slightly closer or farther from the cabinet front edge if desired. The top row of holes is typically calibrated by a one time adjustment of the end stops to 64mm from cabinet top edge to hole center. These adjustments usually need to be made only once when doing the initial set up of the system. The schmitt32 MINI includes the panel locating fixture, the notched guide rail with row numbers, the router base attachment with ratchet pawls, a 5mm bit with adapter bushing, mounting bolts, set up and operating instructions. The schmitt32 MULTI BASE fits the DeWalt model 621 plunge router (shown in the videos), the Craftsman 27683, or the lower priced Masterforce 241-0974. NO ROUTER IS INCLUDED!
