Scotchman Ironworker Custom Modified Punch Gauging Table Fits Portafab45/50514cm

US $850.00

  • Toledo, Ohio, United States
  • Feb 13th
Open on mobile:
QR code
Easily punch out materials much more accurately in a fraction of the time with this assembly.  It was made for producing wrought iron fence, but is invaluable for quickly and repeatedly punching out any type of multi-hole jobs.         This multi-function gauging platform provides all of the ease of use and options of the stock gauging platform, but was specifically designed to enable the user to easily punch consistently accurate rows in channel or flat stock.     This ability was created to allow fast and accurate hole spacing for punching fence channel for ornamental ironwork.     The precision tooled registration guide comes with pins for 3/8", 1/2", and 5/8" stock and register both round and square.     Included are nine #20 Scotchman punch & die sets. Four of the punch sets were custom made by Scotchman to provide close tolerance spacing for tighter fits. The sets are 11/16",17/32",13/32",13/16" round and 17/32" square. The 13/16" has some shouldering on it ,but still punches clean.      It also has 1-1/16" round, 1" square and oval punch and die sets for doing 5/16"x3/4" & 3/8"x1" mounting slots. Included is a #20 punch holder The oversize punches are mounted with their own punch holders for easy use.      The original design and production costs for this tool was over $1800 and was recouped the first time we used it.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Country/Region of Manufacture United States
Model Porta Fab 45 / 50514CM
Brand Scotchman
