FOR SALE Screen Imagesetter, Model DT-R3075, and LD-T 1100 online processor This a drum-type recorder, purchased new in 1998. It handles 26-inch and 30-inch film or polyester plates online in dual cassettes. May be able to convert to polyester-plate processing. We did not use this for plates but it is listed in the specifications. The maximum image size is 21.3x29.3. The online processor is functioning perfectly and has been well maintained and regularly cleaned. See sample of cleaning checklist. This imagesetter has a problem with one of the boards and is SOLD AS IS or PARTS ONLY. It was well maintained during its use. Both units are sold as a package and shipping cost is additional. These are delicate pieces of equipment and require special packaging and preparation – We will package and prepare for shipping for $400 or you can arrange for a 3rd party to package. We will assist in moving the equipment out of our building at no additional charge. Freight costs by a third party are the responsibility of the buyer. If the buyer does not want to ship, the equipment may be picked up in Tulsa, Oklahoma 74104. We could possibly deliver to surrounding states. This delivery charge would be a separate cost and is negotiable. Complete manuals are included. Along with the manuals are hand written notes and instructions that include almost every error and correction the machine has had while in service. All software/hardware sold AS IS. Specifications Recording method External drum scanning Light source : 120 channel LED array (660 nm) Minimum beam diameter 6.35 pm (at 4000 dpi) Resolution 4000, 3000, 2400, 2000, 1500, 1200 dpi (3500 dpi available for particular ) (4000 dpi cannot be selected when paper media is used.) Maximum recording speed 357.2 mm/min. (14.06 inches/min.): For film at 4000 dpi 1190.6 mm/min. (46.87 inches/min.): For film or paper at 1200 dpi Available media types Roll media for LED exposure, wound with emulsion side facing out. (Paper, film, direct plate) When the DT-83075 is used in the EZSYSTEM environment, only paper and film can be used. Media size 550 x 650 mm (21.65 x 25.6 inches: direct plate only) 550 x 660 mm (21.65 x 26.0 inches: direct plate only) 560 x 670 mm (22.05 x 26.4 inches: direct plate only) 581 x 660 mm (22.87 x 26.0 inches: paper and film only) 581 x 762 mm (22.87 x 30.0 inches) Effective exposure size 515 x 634 mm (20.27 x 24.96 inches) when --650 mm-width media width is used: 516 x 650 mm (20.30 x 25.60 inches) when 660 mm-width media width is used. 525 x 654 mm (20.66 x 25.74 inches) when 670 mm-width media width is used: 545 x 648 mm (21.50 x 25.50 inches) when 26 inch-width media width is used. 545 x 750 mm (21.50 x 29.50 inches) when 30 inch-width media width' is used. 545 x 758 mm (21.50 x 29.80 inches) when 30 inch-width media width is used. (Maximum exposure size in special use.) Punch system Stoesser Media mounting and removal Media magazine type (Dual magazine type) Auto loading and auto unloading Drum revolution speed 468 rpm 345 rpm 173 rpm Power requirement: Single-phase 100 to 120 V (50160 Hz) 4 A 0.31 kW or 200 to 240V 4 A 0.3 i kW Grounding Ground resistance of 100 SZ or less. Calorific value 260 kcal ( I 100 BTU) Fuse rating 250V TSA Installing a ground fault interrupter Install a ground fault interrupter if you feel it necessary or local laws and regulations require it. External dimensions (Width x Depth x Height) DT-83075: 848 x 3407 x I 100 mm DT-83075 + Film collection box: 1138 x 1407 x 1100 mm DT-83075 + Film processor: 1765 x 1407 x 1100 mm DT-83075 + Film collection box/film processor selectable type: 2055 x 1407 x 1100mm Space requirement (Width x Depth) DT-83075 + Film collection box: 2338 x 2807 mm DT-83075 + Film processor: 3265 x 2807mm DT-83075 + Film collection box/film processor selectable type: 3555 x 2807 mm Weight 340 kg (including a film magazine) Maximum sound during operation 70 dB (sound pressure level) Operating environment Temperature : 23±3°C (no sudden change) Humidity 50 to 70% (no condensation) Standard accessories Media magazine : 1 set Flange : 2 pieces Optional accessories Media magazine, LD-TI 100 film processor, Film collection box, AT-1 film transport device, AT-2 film transport device Note : Unless otherwise specified, the above values do not cover configurations that include a film processor or film transport device. Total Equipment weight is approximately 700 lbs plus packaging. This will ship from 74104.
