Sds1304cfl Digital Storage Osc, 300mhz,4 Ch.

US $1,399.00

Shoham, default, Israel
Jan 29th

Open on mobile:
QR code

SDS1304CFL Digital Storage Osc, 300MHz,4 ch. Features:Memory depth of SDS1000CFL is 24Kpts Use Colored TFT LCD, the waveform display is clearer and stable Screen saver function: 1 minute to 5 hours 2/4 channel-channel bandwidth: 70MHZ-300MHZ The real time sampling rate is 2GSa/s Trigger Modes: Edge, Pulse, Video, Slope and Alternative trigger modes Unique Digital Filter function and Waveform recorder function Pass/Fail function Thirty two parameters Auto measure function Cursor measure covers Manual mode, Track mode and Auto mode Channel waveform and it's FFT waveform display on split screen Pop-up Menu display pattern is more convenient for users using it Multiple Language User Interface Support Multilingual online help system Weight: 2.5KG Dimensions: 323mmx157mmx135mm (WxHxD) ----------------------------------------------------------------------------- Application: 1. Embedded electronic circuit design and test 2. Mechanical and electrical products design and analysis 3. Education and research 4. Product quality control 5. Real-time signal display 6. Product test, circuit function test Specifications: Model SDS1072/1074CFL SDS1102/1104CFL SDS1202/1204CFL SDS1302/1304CFL Bandwidth 70MHz 100MHz 200MHz 300MHz Channels 2/4CH+1EXT Real time sampling rate 1GSa/s(each channel), 2GSa/s(half channel) Equivalent sampling rate 50GSa/s Memory depth 12K(each channel), 24k(half channel) Rise time < 5ns < 3.5ns < 1.7ns < 1.2ns Input impedance 1M?II13pF 1M?II13pF, 50? Time base range 5.0ns/div-50s/div 2.5ns/div-50s/div 2.5ns/div-50s/div 1.0ns/div-50s/div Scan: 100ms-50s/div Vertical sensitivity 2mV - 5V/div Vertical resolution 8bit Trigger source CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line Trigger types Edge, Pulse, Video, Slope, Alternative Math Operation +, -, x, ?, FFT Digital filter High pass, Low pass, Band pass, Band Stop Max input voltage ±400V(DC+ACPk-Pk), CAT I, CAT II Internal storage 2/4 groups of reference waveform, 20 groups of settings, 20 groups of waveforms External storage Bitmap save, CSV save, Waveform save, Setting save Language English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic Interface Double USB Host, USB Device, LAN, Pass/Fail out Display 7’’color TFT-LCD Power AC 100-240V, 45Hz-440Hz, 50VA Max PC software Can through the computer remote control oscilloscope, extraction waveform analysis data Remark With original source seamless connection, form signal collection, produce integration system Detailed performance parameters and technical index please refer to SDS1000CFL Series Datasheet Model & Contrast: Series Bandwidth Real Time Sampling Rate Equivalent Sampling Rate Memory Depth Channels SDS 1000CFL Series 70MHz,100MHz,200MHz,300MHz 2GSa/s 50GSa/s 24K 2/4 SDS 1000CNL Series 70MHz,100MHz,200MHz 1GSa/s 50GSa/s 40kpts 2 SDS 1000CML Series 70MHz,100MHz,150MHz 1GSa/s 50GSa/s 2Mpts 2 SDS 1000DL Series 25MHz,50MHz,100MHz,200MHz 500MSa/s 50GSa/s 32Kpts 2 Note: the price here is only for:SDS1302/1304CFL payment method: ISRAEL: NEED TO ADD 18% VAT TO PRICE. Paypal Payment Bank Transfer. Shipping: Shipping is Via EMC and insurance is included Items will be shipped within 1 working days after payment has been recieved. If special shipping requirements are needed,please contact us prior to bidding, and we will do our best to meet your needs.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Siglent
Channels	4
Model	SDS1304Cfl
Sample Rate	2GSa/s
Type	Digital
Country/Region of Manufacture	China
Bandwidth	300MHz
