Sencore Sa1454 Portable Signal Spectrum Analyzer (for Professional Installers)

US $2656

Flushing, New York, United States
May 30th

Open on mobile:
QR code

You are buying a new without box Sencore portable signal analyzer this is meant for Cable/Digital TV professional installers. Item is new has not seen any field work. Item will come with ac/dc charger, ac power cord and printed instruction for the device. Instruction are not in a spiral owners manual which originally came with the device. Instruction are PDF print off directly for the Sencore website. The only missing item is the "Rubber Duck Antenna". Actual device pictured, This device has been fully charged and discharged standby battery life is about 6 hours. Display has original screen protector. Item technical specs: Sencore SA 1454 Portable Signal Analyzer with a Full-featured Spectral Display 128 x 128 pixels, 2.5” sq.; Full tuning capabilities from 5 to 870 MHz for testing both forward and reverse path testing and troubleshooting; Fully featured spectral display for viewing your full channel line-up or a specific carrier or frequency to isolate signal problems; Analog signal testing parameters that include RF level, C/N, A/V ratio, and audio output levels. General Information Manufacturer Sencore Manufacturer Part Number SA 1454 Product Name Portable Signal Analyzer Marketing Information The SA 1454 provides you with a full-featured spectral display for finding and analyzing both analog and digital signals. Plus, it provides you with both signal leakage and ingress testing capabilities for complete signal testing confidence. Features Full tuning capabilities from 5 to 870 MHz for testing both forward and reverse path testing and troubleshooting. Fully featured spectral display for viewing your full channel line-up or a specific carrier or frequency to isolate signal problems. Analog signal testing parameters that include RF level, C/N, A/V ratio, and audio output levels. Digital signal parameter testing that includes average peak power, bBer, and digital peak to valley measurements to ensure digital signal quality. Signal Leakage and Ingress testing capabilities to track down signal interference that can cause serious digital signal problems and ensure good quality signals at every drop. Data logging and printing capabilities for system documentation and future drop point comparisons. Plus, built-in voltmeter for quick voltage testing through the coax for cable modem and telephony installs. Specifications Automatic or Manual Spectrum Analysis Frequency range 5-870 MHz Dynamic range >60 dB Resolution bandwidth 100 kHz Reference level TV from 15 dBuV to 126 dBuV or -45 to +66 dBmV -93 to +18 dBm Marker Frequency 5-870 MHz Marker Analog or Digital Automatic Bar Scan from 19 to 120 channels (selectable) Storage of bar scan up to 20 pictures Analog Measurements Frequency band TV and Radio 5-870 MHz Frequency resolution 62.5 kHz Input Impedance 75 ohms Dynamic range measurement 15 dBuV to 126 dBuV or -45 to +65 dBmV or -98 to +16 dBm Measurement resolution 0.01 dB Level measurement acc 1 dB typ. (2 dB max.) A/V ratio 1.5 dB typ. (2 dB max.) C/N ratio 2 dB typ. (4 dB max.) Measurement filter bandwidth 100 kHz @ -3 dB Channel plan memory 600 memory positions Leakage band 115 – 140 MHz Ingress band 5 – 65 MHz Digital Measurement (Emulated digital measurement for 8VSB, QAM 64-128-256) Frequency band 47-870 MHz Power meas. dynamic range from 25 dBuV to 116 dBuV or -35 to +56 dBmV -83 to +8 dBm BER measurement bBER up to 2 x 10-8 Digital signal quality test PASS-MARG-FAIL Based on C/N measurement Multiplex flatness analysis Digital-Degraded-Analog Digital power limit indication Indicates that the signal power is respectively too low or too high General Specifications Voltmeter function AC (square wave), DC, 0 to 100V Channel plan master copy function: (optional via PC) Power supply Built-in NI-CD rechargeable battery: 8 batteries External power supply: 17 Vac or 20 Vdc 1A AC/AC adapter: 120V Battery duration at 25 degree C 4-6 hours in analog mode 3-4 hours in digital Size H 11.8” x W 4.33” x D 2.36” Weight 2.7 lbs. Download port RS232 standard serial port Display 128 x 128 pixels, 2.5” sq. A-20060825-1124-130-E *This item is BRAND NEW - not refurbished. It comes with AC changer & carry case.
