Servicegard Electrical Circuit Analyzer For Lawn & Garden Tractors Jt07324

US $250.00

  • Horner, West Virginia, United States
  • Mar 2nd
Open on mobile:
QR code
You are bidding on a used OTC SPX Serviceguard Electrical Circuit analyzer for JD Garden Tractors JT07324.  Comes from a dealership that went out of business.  This unit works well. Model JT07324 Tests John Deere LX, GT, 300 and 400 series Lawn/Garden Tractors This is the same tester that the JD dealers use to diagnose electrical problems on these JD tractors. A Rare Find! This electrical circuit analyzer will help you determine two important things: 1 It will tell you if the keyswitch module is functioning properly. The analyzer will allow you to to this quickly and accurately. This will prevent unnecessary replacement of the keyswitch module. 2 It will identify the electrical circuit (i.e. Starting, Charging, Cranking, etc.) that has any malfunction. once the analyzer identifies the circuit as having a malfunction, the operating instrictions (included) will give you a starting point on the circuit board connector to begin testing. You will have to use the machine technical manual to complete the diagnosis and repair for that individual circuit. Contents of this JT07324 kit: JT-07324-1 Electrical circuit analyzer unit JT07324-2 Wiring harness for John Deere LX, GT, and 300 series tractors JT-07324-3 Wiring harness for John Deere 400 series tractors Carrying case Operating instruction manuals This analyzer is compatible with the following John Deere tractors: Lawn Tractors: LX172, LX173, LX176, LX178, LX188 LX186, LX255, LX277, LX277AWS, LX279, LX288 Garden Tractors: GT255, GT235, GT242, GT262, GT275, 325, 345 335 and 355 (only above S/N 70,000) 400 series Heavy Duty Lawn and garden tractors including: 415, 425, 445, and 455
