Servo Instruments 14w3-2069 Non Wirewound Precision Variable Resistor - New

US $98.88

Riceville, Tennessee, United States
Feb 21st

Open on mobile:
QR code

Servo Instruments 14W3-2069 Non Wirewound Precision Variable Resistor - New New Servo Instruments 14W3-2069 Non Wirewound Precision Variable Resistor NSN: 5905-00-913-9451 Characteristic Details Effective electrical rotation in deg angular rotation - 320.0 nominal Electrical resistance per section - 100.0 kilohms all sections Actuator travel control feature - Continuous motion Actuator type - Single shaft Ambient temp in deg celsius per section at full rated power - 25.0 all sections Ambient temp in deg celsius per section at zero percent rated power - 150.0 all sections Body diameter - 0.969 inches maximum Body length - 1.480 inches maximum Body style - Cylindrical servo mounted Mounting method - Clamp ring Mounting lip depth - 0.0620 inches nominal Mounting lip diameter - 0.8750 inches nominal Pilot diameter - 0.7500 inches maximum Pilot length - 0.0620 inches nominal Power dissipation rating per section in watts - 2.0 free air all sections Reliability indicator - Not established Resistance tolerance per section in percent - -1.000/+1.000 all sections Rotary actuator travel in angular deg - 360.0 nominal Section quantity - 3 Shaft diameter - 0.125 inches maximum Shaft length - 0.244 inches nominal Shaft style - Round Standard taper curve per section - A all sections Temp coefficient of resistance per section in ppm per deg celsius - -20.0/+20.0 all sections Terminal location - Radially positioned over less than half the circumference Terminal type and quantity - 3 turret Undercut diameter - 0.786 inches maximum Undercut width - 0.0630 inches nominal Please take a look at all of the provided photos before placing your bid to thoroughly inspect the lot contents and condition. Item Condition: New - Old Stock Return Policy: We are offering the buyer a TWO WEEK (14 day) right of return for testing and inspection. Buyer will be responsible for the cost of return shipping. Listed for JP by KK - Located at: P1091 (Q-14W3-2069) on WS Shipping weight is 1lbs, 0oz, shipped from our warehouse in Tennessee. (zip 37370) Default Shipping Service: USPS Parcel Select Tennessee residents will be charged 9.00% sales tax. California residents will be charged 9.00% sales tax. (We have offices in both Tennessee and California and are required to charge tax to any shipment sent anywhere in either state.) B#:
