Servocity 12v Heavy Duty Linear Actuator - (180 Lbs Thrust) 12" Stroke

US $129.99

Winfield, Kansas, United States
Jan 29th

Open on mobile:
QR code

12V Heavy Duty Linear Actuator - (180lbs Thrust) 12" Stroke Move up to 180 lbs for under $130! Our heavy duty linear actuators can be used in place of pneumatics and hydraulics. The heavy duty linear actuators are driven by high torque brushed DC gearmotors coupled to an ACME screw to create a linear drive. The ACME screw provides efficient linear thrust that can handle loads in both the pushing and pulling orientation. The linear actuators can handle an incredible amount of static load and will hold position even when power is removed. The fixed limit switches at each end of the actuator will cut power when tripped to prevent over-run. Each actuator has a built-in potentiometer which can be used for positioning feedback if your application requires. The all aluminum construction with metal drive gears ensures tremendous durability and reliability. We offer them in six stroke lengths from 2 inches up to 12 inches. Extension shaft is .785” diameter. Mounting points are 5/16” diameter and bolt up directly to our optional mounting brackets. ROHS and CE listed. Operating Voltage: 6.0-12 Volts DC Operating Temp. Range: -26 to +65°C -14.8 to +149°F Operating Speed (12V): .30” second at No load Operating Speed (12V): .20” second at Max load Dynamic Thrust (12V): 180 lbs. Thrust Static Load: 500 lbs. Current Drain (12V): 600ma operating No load Current drain (12V): 3.8A operating full load Current drain (12V): 15A at stall (Warning: Damage can occur at stall) Motor Type: 3 Pole Ferrite Potentiometer: I0K Gear Ratio: 30:1 Ratio Gear Type: 4 Metal Gears Connector Wire Length: 24" Recommended Fuse: 5amp inline IP Grade: IP 65 - total dust protection, water resistant Duty Cycle: 25% (25% on, 75% off) Housing Material: Zinc Alloy Feedback Wiring Schematic: White - 10K Potentiometer Reference Blue - 10K Potentiometer Wiper (Position Signal) Yellow - 10K Potentiometer Reference All you need to do in order to get your actuator up and running is apply 6-12VDC to the positive (red) and negative (black) wires. You do not need to do anything with the potentiometer wires (Blue, Yellow, White). The potentiometer wires are only needed if you are building a system which requires you to know the exact position of the actuator piston. For normal operation, we recommend purchasing this switch and wiring the switch according to the schematic above. For questions about this product: tech@servocity.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ServoCity
MPN	HDA12-30
