Set Of 5 Swivel Stem Casters W/ 2-1/2" Gray Rubber Wheel & 5/16" Threaded Stem

US $120

  • Overland Park, Kansas, United States
  • Jun 9th
ITEM TITLE Set of 5 Swivel Stem Casters w/ 2-1/2" Gray Rubber Wheel & 5/16" Threaded Stem Brand: Regent Size: 2- 1/2" X 7/8" Color: gray Style: Regent Non Marking Wheel Condition: New Bearing: 0.38 Capacity: 440 Quantity: Five Casters Overall Dimensions: 2-1/2" Wheel Manufacturer: Durable Wheel Size: 2-1/2" Thickness: 0.87 Swivel Radius: 2-5/8" Top Plate: 5/16" - 18x1" Threaded Stem MPN: (Setof5))TP3025-5/16-Gray Installation Information: Installation Hardware is NOT Included Wheel Material: Non Marking Gray Rubber Number of Items: 5 Package Quantity: 5 CapPerCaster: 110 Part Number: (Setof5))TP3025-5/16-Gray Shipping Weight: 5 lbs. What is a Caster? CASTER:  A caster represents the complete assembly of one wheel, wheel bearings, yoke, axle, and nut, (and optional: thread guards, brakes, swivel locks, springs...),  all of which are assembled together as one complete unit.  There are two basic types of casters. SWIVEL CASTER  (aka CRAZY WHEEL CASTER):  Consists of all of the components of the caster as well as a raceway which contains balls or bearings that allow the caster to swivel. RIGID CASTER  (aka FIXED WHEEL CASTER):  Or stationary caster, or fixed casters consists of all of the components of the caster but does not have a raceway.  (It therefore can roll only in two directions, in a straight line). SWIVEL RADIUS:  Distance measured horizontally from the center of the step or top plate to the trailing edge of the wheel.   This the distance around which the caster will travel while swiveling and the amount of space needed from the center of the wheel to any obstacles. TREAD WIDTH:  Width of wheel at the point of contact with the floor.  This is not usually the widest point of the wheel or the narrowest point.  The widest point is usually on the sidewall and the narrowest is usually at the hub or very center of the wheel.  Bearing spanners are usually inserted to increase the center width of the center of the wheel and decrease the inside diameter of the wheel. CASTER SIZE:  Determined by wheel diameter.  For example if you ask about a 6" caster, we assume you are talking about a 6" wheel even thought the caster overall height will be 7" to 7-1/2". OVERALL HEIGHT:  Vertical distance from the floor to the top of the mounting plate or the top of the swivel raceway for a stem caster.  The working load height of the final item.  If the caster has a stem, the overall height does not include the height of the stem. FRICTION or CAM BRAKE:  Stops (or slows) the wheel by applying pressure from the side between the wheel and the forks.   Not the most positive type brake, but relatively cheap and works in many applications. TOP LOCK BRAKE:  Bake petal is normally on the side of the caster, but sometimes on the top below the plate or stem mount.   Petal engages a pad that clamps down on the wheel for a very positive lock.  Since the pad is metal, this brake can be less effective when used with a metal wheel.  This brake is sometimes referred to as a Tread Lock Brake. TOTAL LOCK BRAKE:  Engaged via a petal that when depressed locks the wheel and the swivel section of the caster.   Very positive braking action, but cost more than other types of brakes.   With the wheel and the swivel locked down, the caster becomes a foot with no movement side to side or around. SWIVEL LOCK OR DIRECTION LOCK BRAKE:  Usually has a pin that pulls out and when inserted back into the swivel section, prevents the caster from swiveling.   This turns a swivel caster into a rigid caster.   Normally has 4 positions to lock the swivel at 90 degree offsets.   Very useful for some applications and can be combined on some casters with a top lock brake.   Also called a "Position Swivel Lock" at times. SIDE LOCK BRAKE:  Another name used for both Friction Lock and Top Lock Brakes when the brake petal is on the side of the caster.  Usually refers to a brake that activated from the side and locks only the wheel from the top. KINGPIN:   The caster kingpin is the pin in the center of a plate caster that holds the plate to the wheel forks.  On a stem caster, the radius is from the trailing edge of the wheel to the center of the mounting stem. BEARING:   The bearing in a swivel caster is located above the wheel at the center of the plate or stem mounting cap.  The bearing in a wheel is at the very center of the wheel and can be one of many types.  (Ball Bearing: uses balls inserted into a housing that allows freedom of movement and usually includes one bearing in the center of two with one located at each side of the wheel, Anular Bearing: uses balls like a ball bearing but has a single piece that spans the entire width of the wheel to create a complete solid point of contact for the axle, Delrin Bearing: Nylon or solid poly self lubricating insert that is usually white and acts as a simple and cost effective way to allow freedom of movement without requiring any grease or oil and has no moving parts.) HUB WIDTH:   The distance from one side to the other side of the wheel at the very center without the bearing installed.  Is almost always different that the width of the wheel. STEM TYPES:   There are many styles and sizes of stems.  Plate casters have a small plate with 2, 3, 4 or 6 holes for mounting.  Threaded stem casters use nuts and come in several sizes and threading styles.  Grip stem casters have solid posts of varying sizes and have a flexible ring to hold the caster in place.  Friction stem casters come in a variety of sizes and simply slide into place and use the weight of the chair to keep them in place. CAPACITY:   The listed capacity is the total for all casters included in the listing.  If the listing is for just one caster the total capacity listed is per caster.  If the listing is for a set of four casters the listed capacity is for the set of four casters.  Capacity is the total weight the casters can hold in a static mode.  That means the capacity is based on a steady, non-moving, impact free, long-term use. There are many styles of casters and not all will easily fit the basic description. FREE SHIPPING OFFER IS ONLY AVAILABLE IN THE CONTINENTAL USA. Hand Trucks and Casters, Inc. 11305 W 87th Terrace Overland Park, Kansas 66214 800-235-7719 ·         Free Shipping is for 48 contiguous United States Only ·         Capacity is total for listed quantity ·         Magliner Aluminum Hand Trucks ·         B& P Made in the U.S.A. Aluminum Hand Trucks ·         Wesco Aluminum and Steel Hand Trucks and Utility Carts ·         Stevens Appliance Dollies ·         Wood and Aluminum Platform Trucks ·         Movers Dollies ·         Aluminum Dock Plates ·         Dock Boards ·         Walk Ramps, Undercarriage Slider Ramps, Curb Ramps ·         Casters: Shepherd, Colson, Albion, DuraStar, Durable, Blickle, MedCaster and more ·         Material Handling Equipment ·         Movers Equipment, Pads, Straps ·         Casters and Wheels Parts and Service Warehouse and Storefront in Kansas City Open 9 to 4 Monday thru Friday                            1-800-235-7719   Hand Trucks and Casters will make exchanges or refunds under the following conditions: You can cancel for a full refund if your order has not already shipped. If an order has shipped prior to your request to cancel the order being received we will refund the price of the item less the actual shipping cost. In the case of items with FREE shipping, free is not the actual cost. If we make an error on your order we will pay the return shipping and refund the full amount of your order plus the cost of your return shipping or replace the item and pay all the associated costs. If you decide that you did not purchase the correct product, made a mistake or no longer want an item we will authorize a refund for the purchase price minus actual shipping costs and up to a 25% restock fee may apply. We will not pay the return shipping. No Refunds on Ramps, Walk Ramps, Dock Plates, Curb Ramps, Slider Ramps or any Special Orders for buyer’s remorse. We will not issue a refund if the item has visible (customer caused) damage or signs of use. Returns or exchanges can be made within 14 days of receiving the product. All returned products must be in original condition (not used, not installed, and not damaged with all original packaging material included). Some items are damaged during shipping. This is not common, but it happens. If an item is received in an obviously damaged package or box, please indicate that when signing for the item.   Shipping Charge Guidelines We do not ship FREE to Hawaii, Puerto Rico, Alaska, APO/FPO Addresses, PO Boxes and all addresses located off the continent of North America.  Your Shipping Choices: 1.     Economy Shipping ·         Can take up to 9 business days to arrive. ·         Least expensive option. ·         Tracking is not always available. 2.    USPS Priority Mail  /  FedEx Ground  /  UPS Ground ·         Usually arrives in less than 5 business days.    (Most continental U.S. locations) ·         More expensive shipping option. ·         Tracking is always available at each step of the shipping process. As you checkout you will be asked to choose the method of shipping that best suits your needs.  Economy (Slow)       or       Priority (Faster)
