Full Set Manual Pad Printer with Sealed Ink Cup Kit Pad printing is a printing process that can transfer a 2-D image onto a 3-D object. This is accomplished using an indirect offset (gravure) printing process that involves an image being transferred from the printing plate (cliche) via a silicone pad onto a substrate (surface to be printed). Pad printing is used for printing on otherwise impossible products in many industries including medical, automotive, promotional, apparel, electronics, appliances, sports equipment and toys. It can also be used to deposit functional materials such as conductive inks, adhesives, dyes and lubricants. Physical changes within the ink film both on the cliche and on the pad allow it leave the etched image area in favor of adhering to the pad, and to subsequently release from the pad in favor of adhering to the substrate (material being printed). The unique properties of the silicone pad enable it to pick the image up from a flat plane and transfer it to a variety of surface (i.e. flat, cylindrical, spherical, compound angles, textures, concave surfaces, convex surfaces). Why use pad printing ? Pad printing is used for printing on various substrates like Plastics, Metals, Glass and Ceramics, Paper and Cardboard, Leather. However, it is primary used in places where the printing area is small and / or the contour or surface of the object is not flat or hard to reach by other printing process. * Engineering items * Golf products * Hangers * Highlighters * Key rings * Letter openers * Lighters* Mugs * Page up * Paper weights * Pens * Pencils * Rulers * Sunglasses * Ashtrays * Bicycle helmets * Brochure holders * Business card holders * Calculators * Cassettes * Coasters * Computer products * Construction helmets * Badges * Telephone boards * Toys * Mobile phone holders Pad printing work includes 2 processes: Plate making Process and Printing Process Plate making Process Printing Process Manual Single Color Pad Printer with Sealed Ink Cup Main features High-Magnetic cup without leaking Work table can be adjusted up and down, forward and backward One-handed operation allows the other hand to place objects on the work table at the same time Precision maintained in repeat jobs High flexibility to adapt to different applications Parameters Operation Way: manual Ink System: sealed ink cup Cup size: ?2.76"(?7cm) Maximum printing area: ?2.3"(?6cm) Max length of craftwork: 5.9"(15cm) Horizontal stroke: 4.7"(12cm) Vertical stroke of rubber head: 2.17"(5.5cm) Machine size:14.2"x7.1"x20.4"(36.1x18x51.8cm) Package dimensions:19.3"x12.2"x21.7"(49x31x55cm) Shipping weight: 63.8Lb(29kg) Emulsion Coating Machine Steel plate coating machine can coat photosensitive liquid evenly on surface of steel plate or steel blade by the centrifugal effect caused by high-speed rotation. It is one of the important equipments in the process of plate making and a necessary tool for making high quality plate. Coating by centrifugal rotation, even and flat. With special designed scale, it is easy to install steel plate, which extraordinarily solve the departure in installing. Collocated with speed–adjustable motor, you can adjust speed of the motor with potentiometer to control thickness of coating. With special designed “+”construction, it is more saving of power and easy to clean. Equipped with handle and protection cover, it is safer to operate. Suitable steel plate size:3.5"-8.66"(89-220mm) Machine size: 13.6" X 13.6" X 7"(345x345x175mm) Net weight: 22LB(10KG) Shipping weight: 24LB(11KG) 10.2"X8.3"UV Exposure Unit Main features Rational design, desktop style based on the principles of humanization and practicality, easy to operate. Timer ensures the precision of exposure time. Automatic remember preset time of exposure, run on the basis of preset time when use again. Power auto-off at the end of count down. 4 special UV tubes, uniform exposure guarantees quality. Complete supporting tools, convenient to maintain and replace components. Adopt 0.12"(6mm) thickness high-strength toughened glass board, high compressive strength. The surface is not easy to scratch. Once the glass is broken, it will turn into mosaic fractured state having no sharp edge to insure safety of users. The machine adopts all-metal construction, advanced electrostatic painting inside and outside of the case. With elegant appearance, it is convenient to clean and never rust. . Parameters Exposing area: 10.2"x8.3"(260x210mm) Voltage: 110v Time Range: 0-330 seconds Light power: 48W(six 8W UV fluorescent bulbs ) Machine size: 12.6"x12.5"x4.3"(320x317x108mm) Package dimensions: 14.6"x14.6"x5.5"(370x370x140mm) Net weight: 8.4Lb(3.8kg) Shipping weight: 10.6Lb(4.8kg) Plate Making Liquid These cliche making liquid allows the pad printer to take his film positive artwork and make inexpensive short run cliches. 1-Cleaning liquid 500ml /bottle 2-Photosensitive liquid 250ml /bottle 3-Developing liquid 250ml /bottle 4-Etching liquid 250ml /bottle 5-Stripping liquid 500ml/bottle 6-Syringe cliche-making Steel Plate Cliche These pad printing steel plates use high quality steel, this steel is made to exacting specification for dimensional accuracy, parallelism, flatness and super hardened to ensure accurate, extra long lasting plate life. Produced for the pad printing industry. Wrought by high strength bearing steel High wear resistance at a low cost Sophisticated structure to be etched fine image both streak and halftone Size: thin plate:8.4"x3.9"x0.01"(214x100x0.3mm) Weight: thin plate:0.11Lb(0.05kg) Inkjet/Laser Transparency Film ASC Non-Waterproof Ink-Jet transparent Film is a specially coated, clear film that absorbs quick drying inkjet ink, and controls the shape of fine lines and half tones. This transparent inkjet film is only coated on one side. Print on the coated (matte) side of the film! If you print on the glossy uncoated side, the ink will not dry because it is not absorbed by the coating. For the unique high-tech solution, they can not be conglutinated with each other when folded together. The image is well-resisting and suitable for storage. Note 1: This film also can be used in your laser printer. Note 1: Your wet finger will stick to the coated side. Note 2: Printing side is the non-smooth side. A4 8"x12" (210x297 mm) Ink Thinner This ink thinner is formulated for both pad printing and screen printing and are available in various evaporative rates that support fine tuning of the ink to any printing situation. They have been specially formulated to minimize evaporative fluctuations, provide process balance and enhance production output. This thinner can be used to dilute all kinds of plastic ink, PVC ink and others. 500ml/bottle Black PVC Ink PVC ink is the most popular ink used in pad printing, giving beautiful colors and designs to your favorite t-shirts and other items. It is also used for industrial printing clothing, on items such as dotted and anti-slip gloves. PVC ink requires fine particle resistant fast gelling at low temperatures, excellent opacity, qualities with good printability and anti-blocking. Finished printing features with excellent flexibility and weather resistance. 2.2LB(1kg)/can Pad Rubber head is a carrier which transfers the patterns on the steel plate onto the substrate surface. These pad printing rubber heads is with high print times and abrasion resistance, without any in purities, with good printing effects, permanent and durable. Items included 1 set of Manual Pad Printer with Sealed Ink Cup (011001) 1 set of Coating Machine (011003) 1 set of Exposure Unit (010031) 3 Thin Steel Plates (011005) Oil Cleaning Liquid (011036) Photosensitive Liquid (011007) Developing Liquid (011008) Etching Liquid (011009) Stripping Liquid (011010) Ink Thinner (011032) 5 sheets of Inkjet/Laser Transparency Film (007003) 4 Pads(011037-011040) 1 can of PVC Ink black (008018) 01) Item# Description QTY Unit Note 011001 Pad Printer with sealed ink cup 1 set 02) Item# Description QTY Unit Note 011003 Emulsion Coating Machine 1 Set Default Voltage is 110 v 03) Item# Description QTY Unit Note 010031 10.2"X8.3" Exposure Unit 1 Set Default Voltage is 110 v 04) Item# Description QTY Unit Note 011005 Thin Steel Plate 8-1/2"x3-7/8" 3 sheet 05) Item# Description QTY Unit Note 011036 Oil Cleaning Liquid 500ml/Bottle 1 bottle 06) Item# Description QTY Unit Note 011007 Photosensitive Liquid 250ml/Bottle 1 bottle 07) Item# Description QTY Unit Note 011008 Developing Liquid 250ml/Bottle 1 bottle 08) Item# Description QTY Unit Note 011009 Etching liquid 250ml/Bottle 1 bottle 09) Item# Description QTY Unit Note 011010 Stripping Liquid 500ml/Bottle 1 bottle 10) Item# Description QTY Unit Note 011032 Ink Thinner 500ml/Bottle 1 bottle 11) Item# Description QTY Unit Note 007003 Inkjet/Laser Transparency Film 5 sheet 12) Item# Description QTY Unit Note 011037 Silicone Rubber Pad L-2800 1 pc 13) Item# Description QTY Unit Note 011038 Silicone Rubber Pad L-2810 1 pc 14) Item# Description QTY Unit Note 011039 Silicone Rubber Pad R-0552 1 pc 15) Item# Description QTY Unit Note 011040 Silicone Rubber Pad R-0582 1 pc 16) Item# Description QTY Unit Note 008018 Black PVC Ink - 1KG 1 can
