Sheldon R13, R15, & R17 Precision Lathes Parts List Manual *518

US $20.00

  • Goddard, Kansas, United States
  • Jan 30th
Open on mobile:
QR code
 Sheldon R13, R15, & R17 Precision Lathes   Parts List  Manual For models: Sheldon No.'s R13, R15, R17 Description: This is a Parts List Manual for the Sheldon No.'s R13,R15, & R17 Precision Lathes. It has a  complete parts list with a parts assembly breakdown. It has 27 pages.  To inspect the quality of the manual, and to view select pages,  please click on the gallery images above to enlarge. Includes sections on: Assembly Breakdown Drawings Parts List Number of pages: Approx 27 Condition of original:   Very Good Publication date: N/A Publication No.:  N/A Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice. About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop. Questions? Email: eugene@fabersurplus.com Phone: 316-210-4079 after 11:00 am Central Time Ships USPS First Class Free or Upgrade to Priority Mail for faster delivery. Reprinted from original manual using high quality 24lb paper and comb binding. Covers are printed from 65lb cardstock for extra durability. Sales tax charged for Kansas sales. See my for more manuals.  Be sure to add me to your favorites list!
Condition New other (see details) :
A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes “New Reproduction Manual”
