Shield Stepping Stepper Motor Driver V4.4 A3967 For Arduino Mega2560 Uno R3 Easy

US $630

Sydney, Australia
Jun 23rd

Open on mobile:
QR code

EasyDriver Shield stepping Stepper Motor Driver V44 A3967 Microstepping For Arduino V4.4 The EasyDriver is a simple to use bipolar stepper motor driver that supports microstepping. It can be used to control 3-axis CNCs, robots, home appliances, etc. It's compatible with any source that can output a digital 0 to 5V pulse (or 0 to 3.3V pulse if you solder 3/5V pads). Board is powered by 7V to 30V supply to power stepper motors with any voltage. It has an on board voltage regulator for the digital interface that can be set to 5V or 3.3V. Connect a 4-wire stepper motor and a microcontroller and you've got a precision motor control. EasyDriver drives bipolar motors, and motors wired as bipolar. I.e. 4, 6, or 8 wire stepper motors. This is the newest version of EasyDriver V4.4. It provides much more flexibility and control over your stepper motor, when compared to older versions. The microstep select (MS1 and MS2) pins of the A3967 are broken out allowing adjustments to the microstepping resolution. The sleep and enable pins are also broken out for further control. Note: Do not connect or disconnect a motor while the driver is energized. This may cause permanent damage to the A3967 IC. Features · A3967 Precision Microstepping Driver · MS1 and MS2 pins broken out to change microstepping resolution to full, half, quarter and eighth steps (defaults to eighth) · Compatible with 4, 6, and 8 wire bipolar stepper motors such as popular NEMA 17 · Adjustable current control from 150mA/phase to 750mA/phase · Compatible with Arduino GRBL G-code interpreter for driving 3-axis CNC machines · Breadboard compatible pins · Power supply range from 7V to 30V. The higher the voltage, the higher the torque at high speeds Detail 1 piece Stepper Driver Approximate Dimensions Board Length: 48mm Board Width: 20mm A few words to assist your buying experience Welcome and thank you for visiting! My brief policies are below and are aimed at helping a clear and efficient buying process for you: Postage I will be happy to combine postage to help reduce costs for items purchased in my store. I will post all items from within Australia and following full payment I will typically post within 24 hours. You may choose Standard, Registered or Express Post when completing checkout. Payment I accept PayPal and Bank Transfer for payment. Please let me know if you will be using bank transfer, so that I can look out for the funds. To assist a speedy delivery, I would appreciate prompt payment. However, if you are expecting to delay your payment please let me know, as communication is helpful. Delivery Issues If you any have issues with your delivery, please do not provide neutral or negative feedback – please contact me directly. By communicating, we’ll find an agreeable solution to any problem.
