Short Circuit Calculations Software

US $180.00

Etobicoke, Ontario, Canada
Feb 13th

Open on mobile:
QR code

Short Circuit Analytic version 1.0.6 (SCA V1.0.6) software Free Demo ! Try before you buy ! Short Circuit Calculations Software ! A must have for electrical inspectors and contructors, consulting, specifying, safety and plant engineers, maintenance supervisors, safety managers ! Save hours of tedious hand calculations and take the guesswork out of short circuit studies by automating the process with ARCAD's short circuit software! TRY BEFORE YOU BUY, Click Here to Download Demo ! Demo Note: To install, just run the download file and follow instructions. The Short-Circuit-Analytic version 1.0.6 (SCA V1.0.6) software performs available fault currents calculations in three-phase electric power systems you are working with. The program takes into consideration electrical parameters of the power supply as well as the power distribution system including utility, cables, bus ducts, transformers, generators, motors etc. The SCA program automatically converts the entire system into a unique impedance unit from which the short circuit current at each and every point is calculated. The process is simple, efficient and will save you both money and time. Features and Benefits: Calculates minimum and maximum available 3-phase and phase-to-phase short circuit currents at each bus within your power distribution system Computes contributions from generators and motors Preview, print multi-page radial single line diagrams Saves calculation results and equipment data Takes into account both active and reactive parts of equipment impedance performing comprehensive short circuit analysis. Some industry accepted calculation methods and standards disregard the equipment X/R ratio and apply correction factors to presumably compensate for the error. Such approach introduces up to 15% uncertainty in a single step of adding two impedances alone while applying different correction factors does not quantifies or corrects the error but only amplifies it. Calculate the total available short circuit current, the amount of maximum upstream short circuit current and the minimum available short circuit current contributed by one source only. TRY BEFORE YOU BUY, Click Here to Download Free Demo ! Short Circuit Analytic v1.0 is available by mail in disk format or via download from web server. When you purchase your copy of SCA V1.0, we need you to provide the end-user's full name and company name. This information is used to generate the individual SCA V1.0 registration key.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ARCAD INC.
MPN	Short Circuit Software
Model	SCA-V1
Country/Region of Manufacture	Canada
