Si4432 433.92m Wireless Transceiver Module Distance 1000m Latest Version

US $8.98

SG, Singapore
Jan 29th

Open on mobile:
QR code

Product Related Specifications: Ultra-thin ultra-small (16.5 x 17mm) Good harmonics too easy to FCC / CE certification The penetration ability (measured through 8 floors) Using the latest version of the U.S. SI4432 IC, stable performance Features: Frequency range: 433.92M Sensitivity up to-121dBm Maximum output power: 20dBm Ddata transfer rate:0.123-256kbps FSK, GFSK and OOK modulation Power supply: 1.8-3.6 V Ultra-low-consumption shutdown mode Digital received signal strength indication (RSSI) Wake time Automatic matching and two-way antenna switch control Configurable packet structure Preamble detection 64-byte send and receive data register (FIFO) Low power detection 8-bit ADC and temperature sensor Operating temperature range: -20 ~ +60 ° C Integrated voltage regulator Frequency hopping Power-on reset function Built-in lens adjustment Applications: Remote Control Remote meter reading Home security alarm and remote keyless entry Industrial Control Telemetry Home Automation Personal data records Toy Control Sensor networks Tire pressure monitoring Health Monitoring Wireless PC peripherals Tag readers Pin Definitions: Number Pins definition Description 1 GND N/A 2 GPIO0 Internal has connected the emission control module feet 3 GPIO1 Internal has connected the receiving control module feet 4 GPIO2 Connect the the chip GPIO2 pins directly 5 VCC Connect power positive 3.3 V 6 SDO 0 ~ VDDV digital output, provide the internal control of the register serial back to read function 7 SDI Serial data input. 0 ~ VDD V digital input. The pins for the 4 wire serial data serial data flow bus. 8 SCLK A serial clock input. 0 ~ VDDV digital input. The pins provides the 4 wire serial data clock function 9 nSEL Serial interface choice input pins. 0 ~ VDDV digital input. The pins for the 4 wire serial data bus provides the choice/make can function, this signal is used to indicate a read/write mode 10 nIRQ Interrupt output pins 11 SDN Close input pins. 0 ~ VDDV digital input. In addition to shut down all the mode mode SDN = 0. When SDN = 1 chip will be completely shut down and the content of the register will be lost. 12 GND N/A 13 ANT Pick up the coaxial antenna 50 14 GND N/A Payment To quote eBay when you place a bid, make an offer or buy-it-now your making a commitment to that seller. We expect all buyers to honor their commitments and we do not approve of canceling transactions without cause. All items you commit to buying or you win at auction MUST be paid for within 3 days after sale date or our system will automatically open an unpaid buyer case. This will end up leaving a bad mark on your eBay record and possibly prevent you from making future purchases on eBay. To prevent this annoyance, you HAVE to have messaged us prior to the close of business of the third day. As of now we do all our transactions via PayPal. Shipping Please Note: Import duties, taxes and customs fee are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding. Economy Shipping 15-25days Our delivery time is normally 15-25 days.Please don't give me negative feedback or dispute via Ebay if you don't receive your item within 25 days. After 25 days, if you still not receive your goods please email me so I can resolve the situation asap. I aim for good communication as well as an excellent business reputation and not negative feedback or disputes. Thank you to every customer. Your satisfaction is my goal. We only ship your order to the confirming address that is provided by Paypal. Before your payment, please make sure your address is right in Paypal . If you need to change the address ,please let us know after you win the bid as soon as possible ,or we will be irresponsible for the order no arrival,hope you can understand! Return Policy Any items may be returned for refund within 14 days of receipt. We will refund only item price, no refund of shipping cost. The buyer is responsible for return shipping costs. We refund within 7 days after items received and all items must be in their original conditions. Return is subject to a 10% withdrawal of value of order as a restock fee. CUSTOMER SERVICE If you have any question. Please to contact customer service us though Ebay. We attempt to reply you within 24-48 hours. Please give us an opportunity to respond and resolve a problem for you before leaving negative feedback. OUR FEEDBACK IS VERY IMPORTANT TO US- Great Customer Service IS Our main goal. If you feel you have not received 5 star service in any area, please contact us and give us a chance to resolve the issue prior to leaving neutral or negative feedback or comments. You will receive Positive feedback automatically once you have left feedback on your experience with us. Welcome to our Store
