Siecor Corning Sm Mm Fiber Otdr Plus Multitester Ii W/ Vfl 340m 340m-5710

US $3,995.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Siecor OTDR Plus Multitester II MainFrame (BC# 16710) Siecor 340M-5710 SM MM Module (BC# 16713) Power Meter: 850nm 1300nm 1310nm 1550nm Interchangeable ST Connector For Power Meter MM OTDR Source: 850nm 1300nm Interchangeable ST Connector For MM Source SM OTDR Source: 1310nm 1550nm Interchangeable ST Connector For SM Source VFL ST Connector For VFL (2) SM ST-ST Fiber Cables (2) MM ST-ST Fiber Cables (4) Fiber Optic Wipes AC Adapter/Charger Power Cord RS232 PC Interface Cable User Manual On CD-ROM Strap For Unit Hard Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Siecor OTDR Plus Multitester II MainFrame With Siecor 340M-5710 Singlemode 1310/1550nm Multimode 850/1300nm OTDR Module w/ Power Meter & VFL Dynamic Range: 850 / 1300 nm : 20.5 / 22.5 dB 1310 / 1550 nm : 32 / 30 dB Power Meter: - 850nm - 1300nm - 1310nm - 1550nm Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Applications LAN Telco CATV Description The Model 340 OTDR Plus™ Multitester II offers true multitesting capability that features field-installable single-mode, multimode and quad OTDR modules, visual fault locator, as well as optional built-in power meter and laser source. The standard unit provides internal solid-state memory for 125 traces and a floppy disk drive. An optional hard drive is also offered to allow mass data storage and speeds testing by eliminating the need to constantly exchange floppy disks in the standard drive. The product line offers a large variety of high-performance multimode and single-mode modules featuring a superior single-mode unit with 46 dB dynamic range. SoftView™ Emulation Software provides desktop analysis and quality documentation capability. A large 10.4-in (26.4 cm) display is easy to read and eliminates the need to jump from screen to screen to view results. Because it is active matrix color, readability is further enhanced. The extraordinary strength, durability and weather resistance of the custom polymer housing protects your equipment investment. Troubleshooting with the 340 is quick and easy with the SmartTest™ Function. At the touch of a button, the 340 selects the parameters and then tests the fiber. The DualTrace™ Function tests and displays both wavelengths on one graph. The multitasking operating system provides fast fiber analysis and data collection. The DualPulse feature allows measurement of the same fiber with two pulse widths to optimize resolution and distance measurements. Repetitive testing and documentation of each fiber is reduced to the shortest possible time using the AutoIncrement™ Function. Only one button per fiber is needed to record both a trace and event table at both wavelengths. Pop-up dialog boxes guide you from fiber-to-fiber and provide warnings if a fault of above-threshold loss is found. Features / Benefits SmartTest™ Function provides a fast, one-button analysis of the entire fiber AutoIncrement™ Function speeds up repetitive as-built testing in high-fiber-count projects, saving time, money and reducing error DualTrace™ Function shows optimal traces at both wavelengths on one graph for easy analysis Large variety of high-performance modules available – single-mode up to 46 dB offers significant distance capacity and enhances event search capabilities Multitest capabilities offer all-in-one convenience on a field-upgradeable platform SoftView™ Emulation Software for batch printing and editing, trace overlay and bidirectional analysis Large display with active matrix color eases eyestrain during periods of extended use Commercially available rechargeable batteries offer hours of autonomous operation AC adapter as well as a 12 V DC power adapter Multilingual operating and help screens Quick and efficient location of fiber breaks and previous event for landmarking Flexible Universal Connector System Telcordia compliant, including GR-196 formatted traces Level 3 approved The Multitester Concept The 340 combines single-mode, multimode and quad OTDR capabilities along with a power meter, visual fault locator and stabilized singlemode light source into a compact platform that resides in a rugged polymer housing. Virtually any field testing can be accomplished with the unit. Capabilities include incoming reel inspections, link loss measurements, fiber attenuation (dB/km), splice and connector loss, reflectance and optical return loss measurement, length measurement, visual fault location and a 2 kHz test tone for fiber identification. With the many range and test options available, the unit can be optimized for access, data center, telco or CATV applications. Specialty modules for water intrusion (1244 nm) S-band (1410 nm) and out of band (1625 nm) testing are also available. Because the platform is modular and field-installed, OTDR and VFL options not ordered initially can be added at a later date. OTDR Functions The 340 is two OTDRs in one – single-mode and multimode – making it ideal for LAN testing, where both fiber types are common. With up to 46 dB of single-mode range available, the 340 is a powerful tool for telco and CATV applications as well. Power Meter The built-in power meter options make end-toend testing easy because data can be saved to disk and analyzed/printed with the same software used for OTDR traces. For CATV applications, a range of +20 dBm is available. Visual Fault Locator The field-installable VFL makes fault location within the OTDR’s deadzone possible as well as provides visual continuity checks. Single-mode Source Units equipped with single-mode OTDR capability can also be equipped to function as a stabilized laser source for loss measurement. 2 kHz Test Tone Fiber identifiers such as the CheckPoint™ and CheckPoint Plus can recognize this tone to locate a fiber at a splice or repair point. Fault Locate Function The OTDR operates as a simple fault locator. At the touch of a button, the unit quickly and accurately finds the end of the fiber. SmartTest™ Function Think of the SmartTest Function as the built-in expert. One key press will select the best parameters for the connected fiber, acquire the data and present both a trace and an event table on one screen. Both novice and expert will benefit from quick and complete fiber characterization. For the novice, getting good results requires only minimal equipment knowledge. For the expert, the SmartTest Function can quickly set machine parameters. DualTrace™ Function On one screen, the DualTrace Function characterizes a fiber at both wavelengths, optimizing the pulse width for each. Visual comparison of performance at each wavelength is greatly enhanced by combining both traces into one graph. Wavelength-dependent losses, such as bending and pinching in splice trays, tight bends in cable placement and compression due to temperature extremes, are also easier to identify in the DualTrace Function view. Such events will exhibit greater loss at the longer wavelength, both on the traces and in the event table. DualPulse Function A fiber is tested at a single wavelength with two pulse widths. Two traces are displayed, one for each pulsewidth. The short pulse provides optimal event resolution, while the longer pulse provides excellent distant measurements. AutoIncrement™ Function Documentation of new installations and repairs is performed quickly with the AutoIncrement Function. This function can create traces and event tables at both wavelengths, save them to disk and prompt the user for the next fiber when ready. If any un-acceptable losses are detected, the user is informed before proceeding. Sequential file names are automatically incremented for each fiber in the test. Data Storage Data is stored to either the internal solid-state memory, a standard floppy drive or an optional hard drive. More than 80,000 traces can be stored on the internal hard drive. Floppy disks may be created directly from the hard drive. Data can also be stored in other compatible file formats such as the standard Telcordia GR-196 format. PC Emulation Software SoftView™ Emulation Software turns a notebook or office PC into a fiber analysis workstation with powerful batch printing, reporting and editing tools. Virtually all the functions available on the OTDR are available on the PC for data stored to disk. SoftView Emulation Software provides manual operation with view trace, eight-trace compare, Telcordia GR-196 formatted trace measurement, save and recall, plus fast analysis and batch printing, fast templates, bidirectional analysis and global processing. Siecor 340M-5710 Module 850/1300/1310/1550 nm MM/SM with +10 dBm meter Specifications: Center Wavelength 20/± 20 nm 850/1300 nm 1310/1550 nm Dynamic Range 20.5/22.5 dB 32/30 dB Attenuation Deadzone 8/9 m 11/12 m Reflective Deadzone (typical) 3 m (multimode) / 3.5 m (single-mode) Pulse width (wavelength dependent) 4 ns to 10 µs (multimode); 10 ns to 30 µs (single-mode) Spectral Width (RMS) 10 nm Loss Resolution 0.001 dB Distance Resolution 0.0001 km; 0.01 meters; 0.001 kft; 1ft; 0.0001 mi Distance Sampling 0.25, 0.5, 1, 2, 4, 8, 16 m (range dependent) Distance Accuracy 0.0025% of distance measurement +/- distance resolution +/- index uncertainty Laser Certification CDRH class 1 requirements (eye safe) 21 CFR VFL Specifications: Wavelength 635 ± 10 nm Output Power = -2 dBm (0 dBm max) Transmission CW or 2 Hz (blink) Connector (fixed) FC, SC, or ST® Compatible Laser Certification IEC 825 Class 2, FDA (21CFR), Class 2 Power Meter Specifications: Calibrated Wavelengths 850/1300/1310/1550nm Optical Meter Range (factory-installed) Standard: +10 to -55 dBm CATV: +20 to -45 dBm, with mf-460 filter Detector Type 2 mm Ge PIN photodiode Wavelength 800 - 1800 nm Resolution 0.01 dBm, 0.01% Watts Store Reference Mode Yes Accuracy ± 4% @ +5 to -50 dBm ± 8% @ +10 to +5 dBm and @ -50 to -55 dBm Linearity ± 0.04 dB, +5 to -55 dBm Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your listings on autopilot with Kyozou eBay Listing Management Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Siecor
Model	OTDR Plus
