Siemens Access 9340dc Power Meter With Enclosure, Documentation

US $248.00

Arvada, Colorado, United States
Jan 29th

Open on mobile:
QR code

Siemens Access 9340DC Power Meter with Enclosure, Documentation nucite The Siemens ACCESS 9340/9360 series power meters combine accurate, 3-phase energy and power measurement with data logging, power quality analysis, alarm, and I/O capabilities not typically available in a compact meter. The meters are ideally suited to local and remote monitoring of low or high voltage electrical installations in industrial facilities, commercial buildings, utility networks or critical power environments. Facility and operations personnel will benefit in energy related costs while avoiding power quality conditions that can reduce equipment life and productivity. ACCESS 9340/9360 series meters are easy to install and use, offering integrated or remote high-visibility displays. A choice of two models and a range of expansion modules help match features to the application and support field-upgrading of meters as required. Serial and Ethernet communication options enable the meters to be used within a Siemens power management system or with third-party automation systems. Technical specifications Current Inputs (each channel) Nominal current 5 A ac Metering range 0-10 A ac Withstand 15 A continuous 50 A 10 sec per hour 500 A 1 sec per hour Burden Less than 0.15 VA Input impedance Less than 0.1 Ohm Voltage Inputs (each channel) Norminal full scale 347 Vac L-N 600 Vac L-L Metering over-range 50% Input impedance 5 Mohm Metering frequency range Metering category III 45-67 Hz, 350-450 Hz Accuracy IEC 62053-22 0. .55 (real energy) ANSI C12 .20 0. .55 Current ± [0. .075% reading + 0. .025% full scale]1) Voltage ± [0. .075% reading + 0. .025% full scale]2) Power ± [0. .15% reading + 0. .025% full scale]3) True power dactor ± 0. 0.002 to 0. .500 leading and ±0. .002 to 0. .500 lagging Frequency ±0. 0.1 Hz at 45-67 Hz ±0. 0.1 Hz at 350-450 Hz Sampling Zero blind 128 samples/cycle Harmonic resolution Metered values 63rd harmonic Wavefrom capture and disturbance detection (9360 only) Manual or alarm initiation 3 Cycles @128 samples/cycle Configurable waveform Sag/swell disturbances I/O Stanard KY output: 3V AC/DC to 240V AC or 300V DC - 1350 Vrms isolation - 100 mA maximum @ 25°C5) Standard digital input - Turn on voltage 20-138 V AC/DC - 5mA burden I/O Option modules - 2 digital out, 2 digital in, 2 analog out, 2 analog in - 2 digital out, 6 digital in, Control Power Universal AC or DC AC control power operating range 115-415 Burden 15 VA max. Frequency 45-67 Hz, 350-450 Hz Ride through 45 ms at 120 V AC DC control power operating range 125-250 +/- 20% Burden 10W max. Ride through 45 ms at 125 V DC Operating temperature Meter -25°C to +70°C 4) Display -10°C to +°C Operating environment Relative humidity 5-95% (non-condensing) Maximum elevation 3000 m Pollution degree 2 Physical Specifications Weight (w/o options) 1.1 lb. (0. .5 kg) Dimensions LxWxH 96x96x88mm Regulatory/standards compliance Emissions Radiated FCC part 15 Class A EN55011 Conducted FCC part 15 Class A, EN55011 Harmonics IEC 1000-3-2 Flicker IEC 1000-3-3 Immunity ESD ICE 1000-4-2 Level 3 Radiated IEC 1000-4-3 Level 3 EFT IEC 1000-4-4 Level 3 Surges IEC 1000-4-5 Level 3 Conducted IEC 1000-4-6 Level 3 Magnetic field IEC1000-4-8 Level 3 Voltage dips IEC 1000-4-11 Accuracy IEC 62053-22 0. .55 (real energy) ANSI C12. .20 0. .55 Regulatory compliance USA UL 508 Canada cUL 508 Europe CE per EN 61010 Communications RS-485 (Standard) Modbus® or JBUS protocol 2-wire connection Up to 38. .4K baud 2nd RS-485/232 port with remote display adapter (optional) Mounting options Panel mount (96x96mm cutout or 4" round hole) Din rail without display, or with remote display Payment Shipping Payment is required within 3 days of auction or listing end. We accept PayPal and all major credit cards. We ship via UPS Ground to all domestic locales. Expedited shipping is available at extra cost. We also ship internationally. Please contact us prior to purchase for shipping quotes to any location outside of the US. We strive to ship all items same or next day on all listings that are paid for on a weekday. Listings ending on the weekend will be shipped Monday or Tuesday. Contact us on all freight items for shipping cost. My Other Auctions • My Feedback • My eBay Store

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“New Surplus. No packaging. Item is unused in excellent condition. Shows minor "shelf wear."”
