Siglent Sdg1020 Signal Generator Function/arbitrary Waveform Generator 20mhz

US $358.99

China, China
Jan 29th

Open on mobile:
QR code

Siglent SDG1020 Signal Generator Function/Arbitrary Waveform Generator 20MHz Special Features: 1.Apply DDS technology, double output, adjustable phase, the highest output frequency is 20MHz. 2.125MSa/s sample rate, 14bit vertical resolution, 16Kpts wave length. 3.Output 5 types of standard waveform, internally installed 48 types of waveform; 4.Internally installed high precision, wide frequency counter, frequency is up to 200MHz. 5.Abundant modulation function, sweep-frequency output, pulse train output. 6.Standard collocation connection: USB Device, USB Host, support U Disk storage and software upgrading; GPIB and LAN port are optional. 7.Can connect to SDS1000 series digital oscilloscope perfectly, and support remote command control. Applications: 1.Analog Sensor 2.Real Environmental Signals 3.Circuit Function Test 4.IC Test 5.Education Technical parameters: Model SDG1005 SDG1010 SDG1020 SDG1025 SDG1050 highest frequency output 5MHz 10MHz 20MHz 25MHz 50MHz output channels 2 sample rate 125 MSa/s wave length 16 Kpts (channel one can choose 512Kpts) frequency resolution 1?Hz vertical resolution 14 Bit waveform Sine wave, square wave , triangular wave , pulse wave ,white noise,48 types of function waveform Sine wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 20MHz 1?Hz ~ 25MHz 1?Hz ~ 50MHz square wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 20MHz 1?Hz ~ 25MHz 1?Hz ~ 25MHz pulse 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz Ramp 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz Gaussian white noise 5MHz bandwidth(-3dB) 10MHz bandwidth(-3dB) 20MHz bandwidth(-3dB) 25MHz bandwidth(-3dB) 50MHz bandwidth(-3dB) wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz 1?Hz ~ 10MHz modulation function AM,FM,PM,ASK,FSK,PWM etc. other functions Frequency counter:frequency is up to200MHz Standard configuration USB Host & Device Optional port GPIB(IEEE-488),LAN product classify function/waveform generator size widthxheightxdepth=229mmx105mmx281mm Standard Accessories: One Power Cord that fits the standard of destination county One USB Cable One User Manual One Set Of EasyWave for WIN98/2000/XP arbitrary Waveform Drawing software Optional Accessories: BNC Coaxial cable GPIB/LAN Interface Software: One Set Of EasyWave for WIN98/2000/XP arbitrary Waveform Drawing software PAYMENT We accept paypal or other payment terms. If there is any import duties or taxes,it is the buyer's responsibility. We often declare it with low value, like $117, so you can pay less tax. Please make payment within 5 days after you place your order. Please DO NOT place your order if you are NOT intend to buy. SHIPPING & DELIVERY We will ship out the unit to you by EMS or FedEx or DHL. It will decided by seller according to your location.(EMS Service Only for Russian Customers) We will ship out the unit to the Express company first, it will take about 2-3 days, and then express company will deal with the package, so you can check the tracking number online after about 4 days. Please note this. CONTACT US Welcome!! Please read ALL POLICIES of us before your purchase. If you have additional questions or concerns about this item, please contact us via email. We will response the most E-mail within 24 hours. RETURN POLICY If the item is defective, please notify us within 7 days after the receipt of the item. The item shall be return in its original condition, in order to get it refunded or replaced.
