Siglent Sdg1025 Arbitrary Signal Function Generator 25mhz 125 Msa/s

US $345.00

The city that never sleeps, Hong Kong
Jan 29th

Open on mobile:
QR code

Up for sale is one piece SDG1025 Arbitrary Function Generator. Description: Enables edition of 14-bit 16kpts arbitrary output waveforms, Arbitrary editing software EasyWave provides 9 standard waveforms: Sine, Square, Ramp, Pulse, ExRise, ExpFall, Sinc, Noise and DC, which meets all engineers’ basic needs; In addition, it provides plenty of ways of manual drawing, point-to-point line drawing and arbitrary point drawing. It facilitates to create complex waveforms; Multi-file screen management helps users to edit multiple-waveform simultaneously. It provides 10 Storage in non-volatile RAM. You can edit and store more waveforms by EasyWave. Features: DDS technology, dual-channel output 125MSa/s sample rate, 14bit vertical resolution. 5 types of standard output waveform, built-in48 arbitrary waveforms Complete set of modulation functions: AM, FM, PM, FSK, ASK, PWM, linear/logarithmic sweep, burst Abundant input/output: waveform output, Synchronous signal output, External modulation source input, 10MHz clock input, external trigger input, internal trigger output etc Channel coupling and duplication function Built-in accurate frequency counter enables to measure ranges 100MHz-200MHz (single channel) Standard interfaces: USB Device, USB Host,Optional interface: GPIB High precision clock(1ppm & 10ppm)is optional Supplied with powerful arbitrary editing software Remote control support Technical parameters: Model SDG1005 SDG1010 SDG1020 SDG1025 SDG1050 highest frequency output 5MHz 10MHz 20MHz 25MHz 50MHz output channels 2 sample rate 125 MSa/s wave length 16 Kpts frequency resolution 1 ?Hz vertical resolution 14 Bit waveform Sine wave, square wave , triangular wave , pulse wave ,white noise,48 types of function waveform Sine wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 20MHz 1?Hz ~ 25MHz 1?Hz ~ 50MHz square wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~ 20MHz 1?Hz ~ 25MHz 1?Hz ~ 25MHz pulse 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz Ramp 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz Gaussian white noise 5MHz bandwidth(-3dB) 10MHz bandwidth(-3dB) 20MHz bandwidth(-3dB) 25MHz bandwidth(-3dB) 50MHz bandwidth(-3dB) wave 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz modulation function AM,FM,PM,ASK,FSK etc. other functions Frequency counter:frequency is up to200MHz Standard configuration USB Host & Device Optional port GPIB(IEEE-488) product classify function/waveform generator size widthxheightxdepth=229mmx105mmx281mm
