Siglent Sdg810 Dds Function Signal Arbitrary Waveform Generator 10mhz

US $282.00

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

The shipment is about 6-9 working days, 3 years warranty Overview: SDG800 Series Function/Arbitrary Waveform Generator is equipped with maximum output frequency of 5 MHZ, 10 MHZ, 30 MHZ, and 125 MSa/s sampling rate. With the new innovated EasyPulse technology, SDG800 can generate pulse of low jitter, quick rising/falling edge regardless of frequency effect, while the duty cycle, edge and pulse width could be widely and accurately adjusted. SDG800 is much superior in performance to similar DDS signal generator. Main Features: 1. Advanced DDS technology,125MSa/s sampling rate, 14bit vertical resolution 2. Single channel output, 5 kinds of standard waveforms, built-in 46 kinds of arbitrary waveforms (including DC) 3. Complete modulation functions: AM, DSB-AM,FM, PM, FSK, ASK, PWM, linear/logarithmic sweep and burst 4. Innovative EasyPulse technology, can output pulse of low jitter, quick rising/falling edge 5. Standard interfaces: USB Device, USB Host, support U-Disk storage and software update 6. Provide 10 nonvolatile storage spaces for user’s arbitrary waveforms 7. Be capable of seamlessly connected to SIGLENT Digital Storage Oscilloscope 8. Configurable with powerful arbitrary waveform editing software EasyWave Design Features: Figure 1 Comparison of edge under 1KHz pulse signal As shown in figure 1, under 1KHz frequency, EasyPulse can keep quick rising/falling edge (20ns) while the edge of ordinary DDS is very slow. Figure 2 Comparison of edge adjusting range under 1KHz pulse signal As shown in figure 2, EasyPulse edge adjustment has a wide range, while ordinary DDS pulse edge adjustment is limited. Figure 3 Built-in 46 kinds of arbitrary waveforms (including DC) As shown in figure 3, SDG800 Series can output 5 kinds of standard waveforms and 46 kinds of commonly used waveforms, including common waveforms, mathematical functions, application functions, window functions and trigonometric functions. Figure 4 Multiple modulation function As shown in figure 4, SDG800 Series support multiple modulation function: AM, DSB - AM, FM, PM, FSK, ASK, PWM, linear/logarithmic sweep and burst. Figure 5 Support PC editing software EasyWave As shown in figure 5, SDG800 Series support powerful PC editing software EasyWave, which can output arbitrary waveform featured 14bit vertical resolution and 16Kpts wave length. EasyWave provides 9 standard waveforms: Sine, Square, Ramp, Pulse, ExRise, ExpFall, Sinc, Noise and DC, which meet all engineers’ basic needs. In addition, it provides a variety of draw modes like manual drawing, straightline drawing(including horizontal straightline, vertical straightline, point-to-point straightline), coordinate drawing and equation drawing, making it easy to create complex waveforms. Multiple Document Interface management makes simultaneous multiple-waveform editing. SDG800 Series provides 10 nonvolatile storage spaces for arbitrary waveforms, and you can also edit and store more waveforms through EasyWave software. Specification Model SDG805 SDG810 SDG830 Maximum output frequency 5MHz 10MHz 30MHz Output channels 1 Sampling rate 125 MSa/s Wave length 16 kpts Frequency resolution 1 ?Hz Vertical resolution 14 bits Waveform Sine?Square?Ramp?Pulse?Gaussian white noise?Arbitrary waveform,46 types of built-in arbitrary waveforms Sine wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~30MHz Square wave 1?Hz ~ 5MHz 1?Hz ~ 10MHz 1?Hz ~10MHz Pulse 500?Hz ~ 5MHz 500?Hz ~ 5MHz 500?Hz ~5MHz Ramp/Triangular 1?Hz ~ 300KHz 1?Hz ~ 300KHz 1?Hz ~ 300KHz Gaussian white noise >5MHz bandwidth(-3dB) >10MHz bandwidth(-3dB) >30MHz bandwidth(-3dB) Arbitrary waveform 1?Hz ~ 5MHz 1?Hz ~ 5MHz 1?Hz ~ 5MHz Modulation function AM?FM?PM?DSB-AM?FSK?ASK?PWM?Sweep?Burst Standard configuration USB Host & USB Device Amplitude (High resistence) 4mVpp~20Vpp(HighZ), 2mVpp~10Vpp(50ohm) Detailed performance parameters and technical guidance please refer to?SDG800 Series DataSheet? Application: ? Simulate sensor ? Simulate environmental signal ? Circuit function test ? IC chip test ? Research and education Standard Accessories A power cord A USB cable A QuickStart Guide A Warranty Card An EasyWave arbitrary waveform editing software A BNC to double alligator clip wire
