Siglent Shs806 Handheld Oscilloscope, 60mhz, 2-channel, Multimeter Mode, 5.7"

US $4019

USA, United States
May 27th

Open on mobile:
QR code

Siglent SHS806 Handheld Oscilloscope, 60MHz, 2-Channel, Multimeter Mode, 5.7" TFT-LCD Display Item Description 60MHz handheld, two-channel digital oscilloscope for viewing electrical signals with multimeter mode for measuring voltage, frequency, duty cycle, and power Real-time sample rate of 1GS/s and record length of 2Mpts for acquiring up to 18 hours of detailed waveforms Advanced triggers for isolation of specific signals 5.7" color TFT-LCD with an internal 8 x 12 division grid for viewing waveforms Meets CAT II 300V and CAT III 150V safety rating Features The Siglent SHS806 is a 60MHz handheld, two-channel digital oscilloscope for viewing electrical signals and has a 6,000-count multimeter mode for measuring AC and DC voltage. The oscilloscope has a real-time sample rate of 1GS/s and a record length of 2Mpts for acquiring detailed waveforms. Four math functions plus FFT (fast fourier transform), and automatic and cursor measurements allow an in-depth analysis of waveforms. Edge, Pulse, Video, Slope, and Alternative triggers allow isolation of specific signals. The oscilloscope's automatic triggering recognizes signal patterns and optimizes triggering, timebase and amplitude settings. The oscilloscope has a recorder that captures up to 18 hours of waveforms. Additional specifications include a rise time of 5.8ns. The unit has a 5.7" color TFT-LCD. The oscilloscope has a USB host port for storing data on a 4GB-maximum flash drive and a USB device port for connecting to a compatible PC. Operating menus and help display in Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Portuguese, Spanish, Japanese, Korean, and Italian languages. The unit operates on a rechargeable battery pack or a 100 to 240V AC, 50/60Hz adapter/charger (both included). It meets CAT II 300V and CAT III 300V safety standards. Specifications Bandwidth 60MHz Channels Two Display 5.7" TFT-LCD (320 x 234 pixels) Power 100 to 240V power adapter, 7.4V 5000mAh battery pack Weight 1.5kg Dimensions (H x W x D) 260 x 163 x 53 mm H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Oscilloscopes are electrical testing devices used to verify the functionality of an electrical signal generator. Oscilloscopes measure an electrical signal over time, and display the waveform signals in a visual graph. The waveform shows the sweeps (or refresh) of voltage on a vertical (Y) axis, and can display time on a horizontal (X) axis. Details of a waveshape demonstrate the signal over time. Oscilloscopes can display in a digital or analog view. An analog oscilloscope has continuous waveform display, typically in a luminous phosphor. Some oscilloscopes can display more than one channel and type of measurement simultaneously. Some oscilloscopes can capture waveform signals to memory, and recall them. Oscilloscopes may provide real-time intensity grading. Some oscilloscopes have the ability to adjust frequency of display. A constant image will display if a signal is shown at a high frequency. Oscilloscopes can be powered with batteries or electricity, or may have a built-in generator. They may have Canadian Standards Association (CSA) or European Conformity (CE) certification, or a specific category (CAT) safety rating, such as CAT5e. Oscilloscopes are commonly used for testing, measuring, and inspecting in science, engineering, telecommunications, automotive, and industry applications. Siglent manufactures electronics test and measurement instruments for research and development, production-line testing, and electronic field service applications. The company, founded in 2002 and headquartered in Shenzhen, China, meets International Organization for Standardization (ISO) standards 9001:2000 and 14001:2004. What's in the Box? SHS806 handheld oscilloscope (2) Oscilloscope probes (2) Multimeter probes Multimeter pen USB cable Power cord User manual Software Additional Information Manufacturer: Siglent Technologies Shipping Weight: 795 Product Dimensions: Width: 13.50 Length: 20.70 Height: 4.20 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
