Signstek Mesr-100 V2 Auto Ranging In Circuit Esr Lcr Meter Capacitor/low Ohm Up

US $74.70

Phoenix, AZ, United States
Jul 14th

Open on mobile:
QR code

Signstek MESR-100 V2 Auto Ranging in Circuit ESR LCR Meter Capacitor/Low Ohm Meter Up to 0.01 to 100R, Support in Circuit Testing Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check. Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. Auto-ranging capacitor ESR and Low Ohm Meter. Wide Measurement Range Using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance will become small, and then we can measure the true series resistor value. A bad E-capacitor have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. Therefore, we can measure the capacitor is bad, damaged or in good condition by using this theory. Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. Advantage of V2: 1) Change square wave to sine wave 100 KHz, reduce square wave's high frequency component, and affect the reading passing the test leads and capacitor. 2)Higher Resolution up to 0.001 ohm. 3)128X64 dot matrix LCD, with larger value display and information 4)Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. 5)New plastic case, curve design for hand carrying. New stand for 60 degree stand on desk. 6)Use 2X AA battery, more convenience and longer battery life than 9V battery. 7)Support external USB power, using standard micro-USB port. Specification: 1)Accuracy: Up to 1% (detail on above table) 2) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range 3)Measuring voltage: 80 Hours Package 1x MESR-100 V2 2 x test clips Shipping We offer FREE shipping on all orders! We ship within Three business days of payment, usually sooner. We use a selection of shipping services such as UPS, FedEx, USPS etc. We only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed. Local pickups and combined shipping options are not provided at this time. Return You can return a product for up to 30 days from the date you purchased it. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. Payment We accept payment by any of the following methods: PayPal Please pay as soon as possible after winning an auction, as that will allow us to post your item to you sooner! Feedback Customer satisfaction is very important to us. If you have any problem with your order, please contact us and we will do our best to make you satisfied. Contact Us If you have any queries, please contact us via ebay. We usually respond within 24 hours on weekdays. Please visit our eBay store to check out other items for sale! Thank you for shopping at our store.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Product	ESR Meter
MPN	US17102402
Capacitance Range	Electrical
Model	Does not apply
Custom Bundle	No
Brand	Signstek
UPC	0710219731090
ISBN	0710219731090
EAN	0710219731090
