Sim7600sa-h 4g Hat For Raspberry Pi

US $76.99

Swanton, Vermont, United States
Aug 10th

Open on mobile:
QR code

Description SIM7600SA-H 4G HAT for Raspberry Pi Designed for Raspberry Pi (Not Included) Communication and GNSS positioning module Onboard audio jack and audio decoder Comes with development resources and manual Supports GPS, BeiDou, Glonass, LBS base station positioning The SIM7600SA-H 4G HAT for Raspberry Pi offers 4G/3G/2G communication and GNSS positioning module, which supports LTE CAT4 up to 150 Mbps for downlink data transfer. It offers a pretty low power consumption. You can connect this 4G module with a computer to surf the Internet, or attach it onto Raspberry Pi to enable functions like 4G high-speed connection, wireless communication, making telephone calls, sending SMS, global positioning, etc. Specifications Power supply: 5 V Operating voltage: 5 V / 3.3 V (configured via jumper) Operating temperature: -30 ~ 80 °C Storage temperature: -45 ~ 90 °C GNSS Receiver type: 16-channel | C/A code Sensitivity: Tracking: -159 dBm (GPS) / -158 dBm (GLONASS) / TBD (BD) | Cold starts: -148 dBm Time-To-First-Fix (open air): Cold starts: <35s | Hot starts: <1s Accuracy: Position: <2.5 m CEP SMS SMS: Supported types: MT, MO, CB, Text, PDU | Storage: USIM card and ME (default) Audio feature: Supports echo cancellation | Supports noise reduction Weight: 0.252 kg What's Included 1 x SIM7600SA-H 4G HAT 1 x LTE Antenna 1 x GPS External Antenna (B) 2 x USB type A plug to micro plug cable 1 x RPi screws pack (2pcs) Dimensions Size 65.15 x 56.21 mm (L x W)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Type	Waveshare
MPN	18799
UPC	Does not apply
