Sim808 Gps Gsm Gprs Module For Arduino Gsm Module Gprs Module Top Quality

US $39.14

shenzhen, China
Jun 9th

Open on mobile:
QR code

Features Overview SIM808 module is a GSM and GPS two-in-one function module. It is based on the latest GSM/GPS module SIM808 from SIMCOM, supports GSM/GPRS Quad-Band network and combines GPS technology for satellite navigation. It features ultra-low power consumption in sleep mode and integrated with charging circuit for Li-Ion batteries, that make it get a super long standby time and convenient for projects that use rechargeable Li-Ion battery. It has high GPS receive sensitivity with 22 tracking and 66 acquisition receiver channels. Besides, it also supports A-GPS that available for indoor localization. The module is controlled by AT command via UART and supports 3.3V and 5V logical level. SpecificationPCB size 50mm X 30.5mm X 1.6mm Voltage Input 3.4V ~ 4.4V Interface UART Indicator NET, STATUS Button POWER Features Quad-band 850/900/1800/1900MHz GPRS multi-slot class12 connectivity: max. 85.6kbps(down-load/up-load) GPRS mobile station class B Controlled by AT Command (3GPP TS 27.007, 27.005 and SIMCOM enhanced AT Commands) Supports charging control for Li-Ion battery Supports Real Time Clock Supply voltage range 3.4V ~ 4.4V Integrated GPS/CNSS and supports A-GPS Supports 3.0V to 5.0V logic level Low power consumption, 1mA in sleep mode Supports GPS NMEA protocol Standard SIM Card Electronic Characteristics Hardware Interface Functions GPS Antenna: this is an uFL GPS antenna connector. You can connect either passive or active GPS antenna to it. Active GPS antenna runs at 2.8V voltage. MicroUSB: the charging interface for Li-Ion battery, of input voltage range from 5V to 7V. Beside, it is also the software debugging interface for SIM808 that you can upgrade firmware and debug software. Power Button: this is the hard power switch for the module. When the module is power up, you can turn on or turn off the module by pressing the button for 2s. Net Indicator: Red LED, it will tell the what status is about the module linking to network. Status Indicator: Green LED, it will tell whether the module is on, light when the module is running. Li-ion Battery: this is power supply for the module, input voltage is from 3.4V to 4.4V. It uses the XH-2.0mm connector, that make it convenient to connect to 3.7V Li-Po Battery. GSM Antenna: this is an uFL GSM antenna connector, just connect it to a GSM antenna for receiving GSM signal. SIM - Card Holder: SIM card holder for standard SIM card Microphone: this is the reserved interface for 2.8V microphone. By using the microphone, you can make voice calls and collect speech data around the module. VRTC: RTC backup. You can add external capacitor or rechargeable battery on it. Pin Map PWR: this is soft power switch for the module, you can pull it to high level for at least 2s to power up or power down the module. RI: this pin will tell you whether the module is on and is there any calls and messages received. It will be pulled to high level when the module is on. And it will change to low for 120ms when a call or message is received. RST: this is reset pin for the module. By default it has a high pull-up. If you absolutely got the module in a bad space, you can pull it to low level for 100ms to perform a hard reset. RXD / TXD: Serial port, the module uses it to send and receive commands and data. TXD is output, and RXD is input. They can be connected to the 3.3V and 5V level. VIO: this is the reference logic level for serial port of the module, the input voltage depends on the logical level of the miccontroller you use. If you use a 5V miccontroller like Arduino, you should have it be 5V, and a 3V logic miccontroller you should set it to 3V. BAT: this pin is connected to Li-Ion battery pin, if you want to use only one Li-Ion battery as your power supply, you can use it to drive you miccontroller. DTR: this is wake up pin for module in sleep mode. By default it has a high pull-up, and you can set the module into sleep mode by AT command “AT+CSCLK=1”. In the meantime, the serial port will be disabled. To wake up the module and enable serial port, you can pull this pin to low level for about 50ms. LED Statu Package Included: 1PCS*SIM808 GPS GSM GPRS Module for Arduino GSM Module GPRS Module TOP Quality Similar Products GPS U-blox NEO-6M Module Aircraft Flight Controller For Arduino MWC IMU APM2 $11.49 Shipping:Free Time left:16d 12h 57m Dual-axis Electronic Digital Magnetic Compass Sensor Module for GPS Navigation $13.18 Shipping:Free Time left:24d 8h 28m New Ublox NEO-6M GPS+HMC5883L Compass module APM 2.6 ARDUPILOT MEGA 2.6 For FPV $14.06 Shipping:Free Time left:6d 5h 29m Ublox NEO-7M-000 GPS Module MWC APM2.6 Replace NEO-6M GYGPSV3-NEO7M NEW $17.65 Shipping:Free Time left:8h 7m 2PCS GPS Ublox NEO-6M Module Aircraft Flight Controller For Arduino MWC IMU APM2 $23.58 Shipping:Free Time left:16d 13h 33m UBLOX Micro GPSV5 NEO-M8N GPS Module GNSS HMC5983 SAW LNA Triple Band Antenna CZ $28.39 Shipping:Free Time left:8h 9m 5PCS GPS Ublox NEO-6M Module Aircraft Flight Controller For Arduino MWC IMU APM2 $55.56 Shipping:Free Time left:22d 2h 3m APM2..52 ARDUPILOT APM Flight Controller Board + Ublox NEO-6M GPS Compass Module $97.66 Shipping:Free Time left:6d 5h 16m Flight Controller GPS Module For PX4 Pixhawk V2.4.5 APM2.56 APM NEO-M8N $20.37 Shipping:Not specified Time left:8h 8m Shipping & Handling Shipping Time: The items you ordered will be shipped out in 1-2 business day by Hong Kong Post Air Mail when your payment is clear. Payment We accept PayPal only. We only ship item to your PayPal verified address. Payment must be received within 5 Days from the date of purchase. Return Policy All the products we are selling include factory warranty, don’t cover items that have been abused, burned and damaged in any form. Please contact us via eBay Message if you have NOT received item in 30 days, we will check it with post office, and then resend or refund any missing item. In the unlikely event that your product is faulty in anyway, you must contact us ASAP and then return it within 7 Days of receipt. The postage and packaging fee will NOT be refunded. We will not be responsible for the delivery or insurance charges incurred in returning item back to us. If you return an item purchased from us, it must be back in Factory Condition. This includes packaging, inserts, manuals etc. Please allow up to 5 Working Days for us to process your returned item. Feedback & Contact Us We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help.We will try our best to solve any problem. If you have any questions, please feel free to contact us by ebay message. We will reply you within 48 Hours. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	SIM808 GPS GSM GPRS Module
Quantity	1
Brand	Unbranded/Generic
Country/Region of Manufacture	China
Model	SIM808
UPC	Does not apply
MPN	SIM808
