Sinclair Fp20107*3 Cavity Filter, Bandpass, High Q, One 7" Cavity, 148-174 Mhz

C $175.00

Kelowna, Canada
Aug 18th

Open on mobile:
QR code

Used Sinclair FP20107*3 Cavity filter, Bandpass, High Q, One 7" cavity, 148-174 MHzAluminum cylinder with brass and copper coaxial inner conductor Silver plating and chromate conversion coating limit corrosion and enhance performance Optional Shadow Bronze finish available Temperature compensated for extremely low frequency drift From the Manufacturer - Product Description: Sinclair’s FP20107-3 series cavity filters are the building blocks of the finest antenna systems. These filters pass a band of frequencies while attenuating frequencies on either side of the desired frequency band. The insertion loss of the passband may be preset at the factory or adjusted in the field. The amount of attenuation (selectivity) can be increased by increasing the insertion loss or using multiple cavities in series. Filter design must recognize the extremely close tolerances required to assure flawless performance over temperature when small variations in electrical wavelength mean significant changes in frequency response curves. Consequently, Sinclair engineers have carefully adapted the FP20107-3 series filter for a variety of applications in the VHF frequency range. The FP series band pass filters are designed to: Protect one receiver further from front-end overload by carriers of co-located transmitters. Suppress IM generation in one transmitter by protecting it further from incoming carriers of co-located transmitters (usually in conjunction with a ferrite isolator). Suppress sideband noise of a single transmitter on co-located receiver frequencies. Generally, “Protect One from Many.’’ Electrical Specifications: Frequency Range MHz 148 to 174 Insertion loss (min) dB 0.5 Impedance 50 Average Power Input (max) W 90 to 400 *1 Input Connectors N-Female Output Connectors N-Female Insertion Loss (max) Tx to Ant dB 3 Mechanical Specifications Width in (mm) 7 (178) Depth in (mm) 7 (178) Length/ Height in (mm) 32.5 (826) Finish chemical conversion Weight lbs (kg) 10 (4.54) Environmental Specifications Temperature range °F (°C) -40 to +140 (-40 to +60)

“Cosmetic marks and scratches. Connectors are oxidized.”

Filter Type

Band Pass

Brand

Sinclair

MPN

FP20107-3
