Single Key Switch Circuit Module 2.5a 15v For Relay Control Flashlight

US $1100

shenzhen, China
Oct 20th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Galler Power Modules Sensors Module Function Modules Development boards Wireless Modules DIY LED Boards LCD Modules Description Single Key Switch Circuit Module 2.5mA/2.5A 15V For Relay Control Flashlight Product Introduction: 2.5mA 1.Function:after power on, it will auto reset,initial state Vo port output low level.Rising edge trigger,trigger once,Vo port output high level;trigger one more time,Vo port output low level;then cycle 2.Power Voltage:DC 2.5V-15V;static voltage:less than 0.1uA 3.Output:ouput port has no driving circuit,output current maximum is 2.5mA;output high level is close to power voltage 4.Applications:self-lock switch transformed into microswitch,flshlight switch 5.Using Method:connect with power 6.Size:11*11mm (not include pin);pin space is 2.54mm 7.Notice:internally installed contact shakeproof circuit,continuous two trigger shoule have 0.5s interval;simultaneously trigger signal width should no more than 0.5s 2.5A 1.Function:add driving audian,is conllector open circuit output structure,adaptive to control relay 2.Power Voltage:DC 2.5V-15V;static voltage:less than 0.1uA 3.Output:can directly drive within 1500mA resistive load for a long time (in a short time can withstand 2500mA) 4.Applications:self-lock switch transformed into microswitch,flshlight switch 5.Using Method:connect with power 6.Size:11*11mm (not include pin);pin space is 2.54mm 7.Notice:internally installed contact shakeproof circuit,continuous two trigger shoule have 0.5s interval;simultaneously trigger signal width should no more than 0.5s;when driving inductive,please pay attention to reserve enough current Pin Definition: 1.VCC:power 2.Vo:output port 3.V1:trigger signal input port 4.GND:power ground Shipping Payment Return Gurantee About us 1. Items are only shipped after PAYMENT confirmed. 2. Please check out your Paypal ADDRESS carefully when processing order. 3. Please CONTACT us ASAP if you haven't received the package in 35 days. 4. If you don't receive the parcel in 45 days, please allow us 3-5 working days for checking undelivered parcels before we issue you refund. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1. If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3. Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.We Can promise to offer you the refund or replacement if you can not get packages on the normal delivery time. 2.If there is any problems with the item when you get it, please send us the ebay message for solution; Or you can return the item to us in 30 days. In our ebay shop, we mainly sell electronics, outdoor finishing accessoires, and all Funny Sorts. We can als offer wholesale service. inkfrog terapeak inkFrog Analytics
