Sinometer Sg1639a Function Generator With Frequency Counter 0.02 Hz To 3 Mhz

US $1300

Montclair, California, United States
Jan 29th

Open on mobile:
QR code

SG1639A Function Generator with Frequency Counter SG1639 series instrument is a kind of precise function generator/counter, the frequency range of main generator is from 0.02Hz to 3MHz (SG1639A). The digital frequency counter can show the operating frequency of generator and test EXT signal’s frequency which less than 15MHz. This unit can be replaced for sine wave generator, square wave generator, triangle wave generator and the frequency counter with the broad frequency range. And so, it is especially suitable for the teaching, science research and experiment about electron circuit and pulse circuit. Note: Sinometer/TekPower/MCP Brand are the same. Technical Data: Main Outputs: 1. Frequency Range: 0.03 Hz to 3 Mhz in 7 steps: 1 Hz,10Hz,100Hz,1Hz, 10Khz,100KHz,1Mhz 2. Wave forms: Sine wave, Triangle wave, Square wave, positive-going sawtooth wave, negative-going saw-tooth wave, positive-going pulse wave, negative-going pulse wave, TTL pulse wave. 3.Output amplitude: >> 20V pp ( no load) 4.Output attenuator: 0dB, 20dB,40dB and 60dB 5. DC offset: 0- ±10V, adjustable 6.Output impedance: 50 O ±10% 7.Symmetry: 10% - 90% Signal Waves: 1. Sine wave: Distortion:< 1% (10Hz - 100KHz) Frequency response: 0.2 Hz - 100KHz << ± 0.5dB 100 KHz - 6 MHz << ± 1dB 2.Square Wave: Rise or fall time: <100ns 3. TTL output: Rise or fall time: <<1 us Low Level:<<0.4V High Level>>3.5V Impedance: 600 O 4. VCF Input Voltage: -5V - 0V Input impedance: 10KO ± 10% 5. Frequency Counter: Measurement range: 1Hz - 20 MHz, 5 digits Input impedance:>>1 MO/20pF Sensitivity: 100mV rms Accuracy: 0.1Hz/1Hz/100Hz Measurement error: <0.003% ± 1 digit Max. input voltage: 150V (AC +DC) (with attenuator) Input attenuator: 0dB/20dB 6. Working environment: Power Source: 110V Temperature: 0- 40 ?C Humidity: RH<=90% Dimension: (WXHXD) : 310 X 80X 230 mm Weight: 1.75 Kgs (4 LBS) Download the user's manual, click here.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	SG1639A
Type	Function Generator
MPN	SG1639A
Type 2	Frequency Counter
Manufacturer	Sinometer
