Sip Mdl#: 620 2 Axis Cnc Jig Borer

US $25,000.00

United States
Jan 30th

Open on mobile:
QR code

SIP MODEL 620 2 AXIS CNC JIG BORER S/N: 608/913 TRAVELS: Working Table travel: 40” (1000mm) Spindle head travel: 28” (700mm) Hydrostatic spindle quill travel: 12” (300mm) Vertical traverse of cross-rail: 30 3/4 ” (780mm) WORKING ENVELOPE: Free space between uprights: approx. 43 1/4 ” (1100mm) Distance from table top to spindle end: 40” (1000mm) Working Table surface: 43 1/4 ” X 33” (1100 X 842mm) Table height: 37” (940mm) Maximum load: 3,300 lbs. (1500 kg) Milling feeds: .05 to 240 in/min. (1 to 6000mm/min.) Rapid traverse: 240 in./min. (6m./min.) SPINDLE HEAD - SADDLE SPECS: Milling feeds: .05 to 240 in./min. (1 to 6000 mm/min.) Rapid traverse: 240 in./min. (6m./min.) Readout Z: .001” (.01mm) 18 Spindle working speeds: 40 to 2000 rev./min. 6 Automatic feeds in both directions: .0016 to .014 in/rev (.04 to .35mm/rev.) Spindle taper: ISO 40 Spindle power: 8 hp (5.9 kW) Hydrostatic quill diameter: 5 6/18” (135mm) Automatic tool clamping Automatic depth stop Spindle rotation reversing Spindle speed preselection Controller: SIP, Societe Genevoise D'Instruments De Physique 2 Axis control Includes large amount of tooling (Approximate value of over $20,000) and all available Manuals: CO ‘L’ bar, adjustable boring bar set Wohlhaupter boring head, Assorted MT holders Assorted end mill & face mill holders set up block, etc. Overall Machine dimensions: 137" (F-B) x 119" (R-L) Height: 108” Est. weight: 25,000# Unit is in Climate controlled storage facility in Tucson, AZ. Unit is in Excellent condition and was fully operational at time of disconnect/storage.Unit is selling "AS IS - WHERE IS" but if BIN price is paid we'll include a 30 day satisfaction Warranty... please see below for details. SELLING AS IS WHERE IS BUYER IS RESPONSIBLE FOR ALL SHIPPING AND RIGGING COSTS WISCONSIN BUYERS WILL BE CHARGED APPROPRIATE SALES TAX UNLESS A WISCONSIN SALES TAX EXEMPTION FORM IS PROVIDED BY THE PURCHASER. BUYERS OUT OF WISCONSIN AND/OR INTERNATIONAL BUYERS WILL NOT BE LIABLE TO PAY FOR OR PROVIDE A SALES TAX EXEMPTION FORM. THEY WILL BE LIABLE TO PAY THEIR OWN STATE OR COUNTRIES SALES TAX ACCORDING TO LOCAL GOVERNMENTS TAX LAWS.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Unit is in Climate controlled storage facility in Tucson, AZ. Unit is in Excellent condition and was fully operational at time of disconnect/storage.Unit is selling "AS IS - WHERE IS"”
