Skynet New Open Frame Power Supply Psu Snp-z067 65w 100-240vac 12v-4.8a 5v-0.5a

US $19.95

  • Mountain View, California, United States
  • Jan 29th
Open on mobile:
QR code
You are bidding on one new power supply. Total 70 units available, shipping is combined. Please bid with confidence but ask questions before bidding. I have tested and used this power supply myself, that is why no longer 80 are available ;-) Model SNP-Z067 for ITE and Medical application, 0 to 70 deg Celcius, convection cooling (no forced cooling needed), derating when over 50 deg C. Continuous power 65W, peak 90W automatic recovery from overload. input 90-264VAC 2-1A 47-63Hz 12V output can adjust between 10-14V (pot 2k with 3.9k to GND and 18k to +12V output, top of pot = 2.5V) peak current is 7.5A while continuous current is 4.8A if also the other output is delivering max power. The 5V output is generated using the LDO PQ05RH11 from Sharp, so it is guaranteed between 4.88 and 5.12V (better than spec) and max peak current 1.5A but continuous 0.5A due to limited heatsink. Click here for the LDO datasheet PCB size:  2"x4" height 1.18"  Power density 6.3W per cubic inch. mounting holes: 1 3/4 x 3 3/4 center distance All specs and datasheet of this power supply can be found here at the manufacturer website EMI certification FCC "B" EN55022"B", EN55011"B" EMS EN61000-4-2,-3,-4,-5,-6,-8,-11 Safety UL 60950-1, UL 60601-1 CSA C22.2 No. 60950-1, No. 60601.1 EN 60950-1, EN 60601-1
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Skynet
Country of Manufacture Taiwan, Province of China
Model SNP-Z067
