Slico Atmega169 Atmel M169 Avr Kit Temperature Pid Controller Cp2102 Output

US $59

Gatineau, QC, Canada
Jun 1st

Open on mobile:
QR code

New implementations, new successes!!! light version !!! compatible with qtouch keyboard from my production as well or any other keyboard at your preference this version has 2 ADC inputs designed in the PCB board UART output for collecting data. Script for software to collect data in computer buffer for LCD space for soldering FT232 or CP2102 this version is equipped with CP2102 In last picture is sown that you can monitor temperature values in time in computer. http://youtu.be/b2udOCLKOTY test for 600C http://youtu.be/4H4MYYjVsQ4 test for 1000C Food Technology 1. Industrial/home/custom Food Oven Kit for home technology implementation and student projects 2. eggs incubator 3. Boiler 4. greenhouse warming other fields of applications Nanotechnology 1. Multi zone reactors (heaters) 2. ZnO nanostructures thermo-annealing reactor. 3. polymerization which depend of precize temeperature changing in time 4. InP nanodots annealing 5. TiO2 annealing for obtaining high quality of Rutile phase Technology 6. Controller for solder station 7. Oven heater area for PCBs Microtechnology 8. Infrared oven for photoresists ETC. Temperature PID controller for development applications til 1000 C The kit incdude: 1. MCU board atmega169 2. keyboard 7 keys (not included, ask me separate) 3. trinistor BTA24/BTB24 board (not included, ask me separate) 4. cable between MCU board and keyboard (not included, ask me separate) 5. LCD 16x2 (not included, ask me separate) 6. 4 cable connectors for trinistor board (not included, ask me separate) 7. the basic k-type thermocouple (not included, ask me separate) The amplifier LM324 adjusting can be done by your self, it will depend of your condition and your precision of using. There are 2 resistors: Zero adjust and Bias adjust, please see for similar adjusting in OP495 datasheet. THE KIT IS PROGRAMED ALREADY WITH DEMO SOFTWARE !!! please consult the board image-datasheet: http://s30.postimg.org/9aypygqzl/fileshare_ro_Poster_PID_en.jpg Heater testing (the test of reactor for semiconductor termo-annealing) http://youtu.be/b2udOCLKOTY http://youtu.be/4H4MYYjVsQ4 I will send worldwide, or combine items in one package, please contact me for more information NB!!! USA and Canada Free Shipping!!! outside of north-America ebayers are welcome. The cheapest post service may cost 7-11$, and it take more than 2 month, there for it is request to give me feedback before sending. It is on your responsibility for choosing cheap post service. Express post with tracking number cost 50-65$ Good luck with your project and thank you for buying my page :) http://www.ebay.com/usr/sli.nanolab.equipments
