Smart Servo Controller For Arduino

US $28.69

Swanton, Vermont, United States
Jul 10th

Open on mobile:
QR code

Description Compatible with Dynamixel AX/MX series servos Power Supply:6.5 - 12V UART interface for deeper development SPI Interface (Digital 10,11,12,13) The Smart Servo Controller for Arduino allows to drive multi servos with a daisy chain connection to your Arduino processor and build robots with powerful servos. This board Integrates a half duplex circuit inside. That means the transmit wire from your UART is connected to all of the AX-12 servos. Because of the servo can be linked by serial bus, which can link up to 200+ servos. Each unit can feedback its position, rotation velocity, torque, current, motor temperature and so on. It can do rotating all around, and the velocity can be controlled, just act as a gear motor. This feature enables it to work as a motor of wheeled robots, or tracked robots. Applications Education Robot Arm Humanoid Robot Hexapod Robot Any other servo driven application Specifications MCU: Atmega8 Power Supply: 6.5 - 12V Arduino R3 Layout Directly compatible with Dynamixel AX series and uptech CDS55xx series servos SPI Interface (Digital 10,11,12,13) Friendly using for the primary user UART interface for deeper development 7 channels for servo connecting A half duplex circuit inside The current hardware version does not allow reading values returned by a smart servo, such as the position. Board Surface: Immersion Gold Size: 59 x 53mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	DFRobot
Type	DFRobot
MPN	DRI0027
UPC	Does not apply
EAN	6959420903146
