Smc Digital Flow Switch For Water Pf2w740-00-67n

US $580

  • Saint Petersburg, Russian Federation
  • Jun 18th
SMC PF2W740-00-67N, Digital Flow Switch for Water, Integrated Display Type Flow rate setting and monitoring are possible with the digital display. Integrated and remote type displays are available for different types of application. Water resistant construction is used conforming to IP65 protection. Switching from real-time flow rate to accumulated flow is possible.                                       General Information Display: Integrated Flow Rate Range: 3.5 to 45 L/min Switch Action: PNP Proof Pressure: +1.5 MPa Maximum Load Current: 80 mA Maximum Load Voltage: 24 V dc Operating Pressure Range: 0 to +1 MPa Operating Temperature Range: 0 to +50 °C Standards Met: CE Signal Response Time: 1 s Piping Type: Body Ported (Side) Overall Width: 73 mm Overall Height: 60 mm Thread Standard: BSPT Overall Length: 120 mm Number of Outputs: 2
