Smt Pick And Place Machine

US $14,900.00

Mechanicsburg, Pennsylvania, United States
Feb 24th

Open on mobile:
QR code

Never used. Brand new bench top pick and place machine. Manufacturer: APS Gold - DDM Noastar, Made in the USA. Provide affordable automatic pick and place operation in a small space. Come with a vacuum pump, computer and monitor with software loaded. Note: The machine is new but not in the original package. Machine stored in a climate controlled environment. Features • Provides affordable automatic pick and place operation in a benchtop system • Individual 8, 12, 16, 24, 32 & 44 mm & 12 lane 8mm tape bank feeders available (not included) • Components including discrete, 0603s, SOICs, PLCCs, and 25 mil pitch QPPs • Easy to set up, easy to program and easy to use with WindowsTM based software • Optional convenient SuperStripTM feeders for short tape strips • System includes 4 position nozzle changer for most SMT component sizes • Placement rates up to 2100 cph • Includes 15” flat screen monitor Specifications Max board area . . . . . . . . . . . . . . . . . . . . . .13.5” x 22” (343 x 560 mm) Max travel area . . . . . . . . . . . 22”(X axis) x 22”(Y axis) (560 x 560 mm) Z axis max travel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5” (38 mm) Board thickness . . . . . . . . . . . . . . . . 0.020”- 0.156” (0.5mm - 4.0 mm) Typical verifiable placement rate . . . . . . . . . . . . . . . . . . 1000-1800 cph Max placement rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2100 cph Placement accuracy . . . . . . . . . . . . . . . . . . . . . . . . . ±0.006” (0.15mm) Fine pitch capability . . . . . . . . . . . . . . . . . . . . to 25 mil pitch (0.635mm) Smallest component capability. . . . . . . . . . . . . . . . . . . . 0603 packages Largest component size . . . . . . . . . . . . . . . 1.378” (35mm) square body Max no. of feeders, 8mm tape width . . . . . . . 64 (individual), 96 (bank) Optional Individual tape feeders . . . . . . . . . 8, 12, 16, 24, 32 & 44 mm (Electrical) Optional Vibratory feeders . . . . . . loose, tube, stick ( Freq. & amplitude control) Optional Matrix Tray Feeders . . . . . . . . . . . . . . . . with Board/Matrix tray holders Component orientation ?-axis motion . . . . . . . . . . . ±360° in 0.90° step CS40 System dimensions. . 40” x 42” x 25”h (1016 x 1067 x 635 mm) Centering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Centering fingers Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 lbs (114 kg) Board holding . . . . . . . Edge clamp w/optional board support tooling Data entry: coordinate entry, “teach” mode with color CCD camera, CAD download Vision system . . . . . . . . . . . . . . . . . . . . . . . . Color CCD card camera (Included) Automatic 4 position tool changer . . . . . . . . additional changer optional Operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Windows® Dispenser option . . . . Time & pressure, clean dry air @ 80 psi required Power . . . . . . . . . . 120 VAC, 50/60Hz Feeder Options L-VF . . . . . . . . . . . . . . . . . . . . . . . Vibratory tube/loose feeder - option L-T (tape feeders). . . . . . . . . . . . . . 8, 12, 16, 24, 32, & 44 mm - option L-MBH . . . . . . . . . . . . . . . . . . . . . Matrix tray holders (set of 2) - option L-SS-XX . . . .Dual Lane SuperStripTM feeder for strips from 1” to 12”- option XX indicates tape width: 8, 12, 16, 24, 32, 44, and 56 mm L-BF-12. . . . . . . . . . . . . . . . . . . . . 12 lane bank feeder for 8 mm tapes - option L-BFRH-12 . . . . . . . . . . . . . . . . . . Reel holder for L-BF-12 bank feeder - option
