Solar Power Junction Box For Lowpower Pv Module,2rails

US $5.72

Shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Flashlight laser mount surefire Solar power Junction box for Lowpower PV module,2railsRF-2335 Overall dimensions:70*70*20mm The Solar Junction Box, designed for robotic-assembly of silicon photovoltaic systems, reduces assembly time and production costs for PV-panel manufacturers. Rugged and durable, IP67-sealed, DC connectors feature simple snap-lock mating and an internal locking mechanism for superior safety. They are designed for direct connection to solar junction boxes, field installations and PV grid wiring. In addition, DC double-insulated cable assemblies, with proven long life cycle and optimum weather resistance, meet the demands of harsh and outdoor solar wiring applications. Main technical parameters Current for PV Module 7A Rated Voltage DC 1000V Protection Degree IP65 Power Capacity 40-50W Solar panel Touch Protection Class II Temperature Range -40°C ~ 85°C Diodes Details 1pcs Number of terminals 2 rails Wire Size 4mm? (default) Optional :1.5mm?- 4mm?or 1.5mm?-2.5mm? Contact Resistance <5 Ohm Flame Class UL94-V0 Contact Material Copper Insulation Material PPO Overall dimensions 70*70*20mm N.W(KG) 0.050KG Product Features: 1.With the capacity of anti-aging and UV resistant, provide longer life span under outdoor bad condition. 2.Adopted reliable connection solution ,simple,quick and safe effective field assembly. 3. Excellent sealing performance, waterproof and dustproof rating up to IP65. 4 With one or two output hole,provide various wire connect way. These cables and connctor will be fitted to Juncation Box: Cable/wire: 1.TUV & UL certificated PV cable 1*2.5mm? 2.TUV & UL certificated PV cable 1*4mm? Shiping inlcuded : 1pcs Solar Junction Box Quantity: 1 PCS Click here view similar items in our store Click here view more items in our store ==============Thanks for your attention ================= Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	weight	0.050KG
Current for PV Module	7A
wire size	4mm? (default)
Rated voltage	DC 1000V
