Solid State 2n3749 Bipolar Junction Transistor, Npn Type, To-111 W/ Hardware

US $19.95

Stanton, California, United States
Jul 21st

Open on mobile:
QR code

SOLID STATE 2N3749 Bipolar Junction Transistor, NPN Type, TO-111 W/ HARDWARE NEW OLD STOCK LOT 30909 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 110.0 MAXIMUM COLLECTOR TO BASE VOLTAGE/STATIC/EMITTER OPEN AND 80.0 MAXIMUM COLLECTOR TO EMITTER VOLTAGE/STATIC/BASE OPEN AND 8.0 MAXIMUM EMITTER TO BASE VOLTAGE, STATIC, COLLECTOR OPEN CURRENT RATING PER CHARACTERISTIC 5.00 AMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 2.0 WATTS MAXIMUM TOTAL POWER DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 200.0 DEG CELSIUS AMBIENT AIR INCLOSURE MATERIAL METAL MOUNTING METHOD THREADED STUD MOUNTING FACILITY QUANTITY 1 THREAD SERIES DESIGNATOR UNF NOMINAL THREAD SIZE 0.190 INCHES TERMINAL TYPE AND QUANTITY 3 TAB, SOLDER LUG AND 1 WIRE HOOK OVERALL LENGTH 0.320 INCHES MINIMUM AND 0.468 INCHES MAXIMUM OVERALL WIDTH ACROSS FLATS 0.423 INCHES MINIMUM AND 0.438 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: NPN

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Mounting Style	Through-Hole
Brand	SOLID STATE
Series	2N3749
Maximum Power Dissipation	2 W
Type	NPN
Package/Case	TO-111
MPN	2N3749
