Solid State Relay Contactor 40 A @ 42-600 Vac, Control 20-275 Vac / 24-190 Vdc

US $53.00

Edwardsburg, Michigan, United States
Jan 29th

Open on mobile:
QR code

Rated Operational Current: 400 mAAC to 40 AAcrms Motor Ratings 115 VAC 230 VAC 400 VAC 480 VAC 600 VAC 1 HP / 0.56 kW 3 HP / 1.5 kW 5 HP / 2.2 kW 5 HP / 3.7 kW 7½ HP / 4 kW Filtering Suggested Filter Max. Heater Current 220 nF / 760 V / X1 330 nF / 760 V / X1 25 AMPS 45 AMPS Function: 1-Phase - Zero Cross Switching Operational Voltage Range: 42-600 VAC Control Voltage: 20 - 275 VAC (24 - 190 VDC) Rated Operational current: 400 mAAC to 40AAC @ 40°C 3200A²s for l²t and 1200Vp blocking voltage Product Width 1.402" (35.6mm) IP20 protection Design according to EN/IE60947-4-2, EN/IEC60947-4-3, EN/IEC62314, UL508, CSA 22-2 No. 14-10 Integrated voltage transient protection with 625V varistor RoHS compliant Short circuit current rating: 100kA VDE approval Mounting: DIN-rail mounting This new range of solid state contactors presents an unique opportunity to maximize efficiency in panel space and is an evolution of solid state switches. The nominal current ratings are at 40°C. The width is 35.6mm and is rated at 40 AAC. Power and control terminals allow for safe looping of cables. Voltage transient protection is standard across the output with a varistor. Specifications are stated at 25°C unless otherwise noted.

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“New items, bubble wrapped, packed and shipped.”
