Sony Dfs-300 Dme - Digital Multi Effects Production Mixer / Video Mixer

US $349.00

Bergschenhoek, Netherlands
Jan 29th

Open on mobile:
QR code

- Sony DFS-300 Production Mixer - A 4-input multi-format switcher with digital effects which is in grate state! Includes over 300 preset effects, wipes and mixes.Includes chroma keyer and color corrector as standard. Options do include the BKDF-301 3D effects board and the BKDF-504 8-bit downstream keyer board. Inputs 1-3 can be either component, Y/C or composite and input 4 can be RGB or component (Y/R-Y/B-Y). Features: 8-bit digital component video switcher Up to 500 2D and 3D digital effects including page turns, page rolls, spheres and waves Built in transcoding with Component, Composite and Y/C inputs/output RGB, RGB/S inputs Built-in chroma keyer and luminance keyer Built-in black burst outputs and 31 color backgrounds 8-bit Linear Downstream Keyer option All input signals are processed in the digital component domain Inputs 1-3 accept signals in three different formats, composite, Y/C (S-Video) and component (Y/R-Y/B-Y). The fourth channel accepts either component (Y/R-Y/B-Y), R/G/B/Sync or an R/G/B signal from PCs and other image processing equipment. Simultaneous outputs in component, Y/C and composite. 31 backgrounds including embossed patterns, variable colors, grid patterns, color bar and black are provided. Three mattes for color background, border and effect can be generated as standard. A FRGD source such as a title, caption or figure can be self-keyed over a BKGD source and rotated, compressed and positioned optionally in 3D space. The built-in chroma keyer superimposes video from a FRGD source onto a BKGD source. Clip and Hue can be controlled to provide clear and sharp key edges. If the input signal color level is incorrect, fine adjustment is available in the unit. When used with a Sony Editing Controller such as the PVE-500 or RM-450, the DFS-300 allows two-machine editing with effects. Eliminates need for TBCs on VTR. Even live camera sourcescan be input to the switcher and be locked instantly. Connector: 12-pin (x 1, each) Video: 1.0Vp-p, 75 Sync: 0.286Vp-p Burst: 0.286Vp-p Y: 1.0Vp-p, 75 C: 0.286Vp-p, 75 R-Y/B-Y: 0.7Vp-p (100/7.5/77/7.5 color bars) G: 0.7Vp-p, 75 R-Y: 0.7Vp-p, 75 (100/7.5/77/7.5 color bars) B-Y: 0.7Vp-p, 75 (100/7.5/77/7.5 color bars) Editor: D-sub 9-pin, 9-pin remote (RS-422A) Frequency response: 0 to 5mhz (Ref. 1 Mhz) +0.5db/-1dB(Y/C, component) Linearity: DG 3.5% (composite input)2.0% (component/S input)DP 2.5o (composite input)1.0o (component input) Crosstalk: Less than -50dB S/N: 51 dB (composite)55 dB (Y/C, component) Y/C delay: Less than 20ns (component)Less than 50ns (composite) Power Consumption: 80W Operating Temperature: 0 to 40o C (32 to 104oF) R:: 0.7Vp-p, 75 B:: 0.7Vp-p, 75 Y:: 1.0Vp-p, 75 G:: 0.7Vp-p, 75 R-Y:: 0.7Vp-p (100/7.5/77/7/5 color bars) T1/CUE IN/T2 IN:: BNC type (x 1, each), TTL level CONTROL PANEL: D-sub 25-pin, 25-pin remote (RS-422A) Y/R-Y/B-Y: 8 bits Power requirements: AC 120V, 50/60Hz Operating voltage: AC 90 to 132 V, 48 to 63Hz B-Y: 0.7Vp-p (100/7.5/77/7/5 color bars) Y: 1.0Vp-p, 75 Y:: 910fH (fH: 15.734kHz) Burst: 0.286Vp-p Burst: 0.286Vp-p, 75 Connector: 12-pin (x 1, each) Connector: BNC type0.286 to 4.0Vp-p, 75 Connector: BNC type ( x 1, each)1.0Vp-p, 75 Connector: BNC type (x 1, each) Connector: BNC type (x 2, loop through) Connector: BNC type (x 3) Connector: DIN-4-pin (x 1, each) R-Y/B-Y: 0.7Vp-p (100/7.5/77/7.5 color bars) R-Y/B-Y: 1/4 x 910fH R:: 0.7Vp-p, 75 Sync: 0.286Vp-p Sync: 0.286Vp-p, 75 Video: 1.0Vp-p, 75

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Only used by professionals with care, item is fully functionally and looks great”
