Soundtube Cm62-ezs-ii-wh Ceiling Mounted Speaker

US $240

Chico, California, United States
Aug 2nd

Open on mobile:
QR code

From the Manufacturer: SoundTube CM62-EZs-II Coaxial In-Ceiling Speaker in White The next generation version of the CM62-EZs with improved and additional features. Engineered for applications with limited plenum space, incorporating a SoundTube-specific shallow backcan with an installed depth of only 3.5 inches. One 6.50 in (165.0 mm) treated fiber woofer with cloth surround and one 1.00 in (25.4 mm) silk dome tweeter. Easy-access six-position tap switch for 25/70.7/100-volt and 16 ohm transformer bypass position allows for easy ordering, stocking and installation. Reduced amplification costs with maximum efficiency including 90.5 dB sensitivity and 16 ohm impedance. Superior voice intelligibility with a 10 kHz coverage angle of 80 (independently verified). Cost-effective 16 ohm settings allows for the use of multiples of two, four, or six speakers in a system using a standard amplifier without a trans former. Incorporates a painted steel grille for lasting durability. Ceramic input terminal accepts up to 10 gauge plenum rated signal wire and includes thermal fuse. Suitable for use in voice alarm applications subject to EU regulations EN60849 and BS5839-8. EN54-24 listed. Adaptable to material thicknesses ranging from 0.04 inch (0.9 mm) 1.60 inch (40.6 mm). UL 1480 (UEAY) and 2043, cUL, CE (EMC Directive 89/366/EEC, EN55020, EN55013) approved. Specifications: More InformationColor White UPC 752830442689 Manufacturer SoundTube Manufacturer's Category CM-EZ Economical In-Ceiling Shipping Weight 9.15 lbs / 4.15 kg Carton Height 6.25 in / 158.75 mm Carton Length 13 in / 330.2 mm Carton Width 13 in / 330.2 mm Certifications CE, EN54, RoHS, UL1480A, UL2043 Enclosure Properties ABS Glass Fiber Reinforced, Injection Molded, Sealed Enclosure Volume 350 cu in / 5735.47 cu cm Included Accessories Conduit Clamp, Cover Plate, Grille, Paint Mask Optional Accessories White Grille (GRL-CM6/8EZ-II-WH)|Tile Bridge (AC-CMEZ6/8-TB)|Pre-Construction Bracket (AC-CMEZ6/8-PCB)|Junction Box (AC-CM-EZ-JBOX) Source Inputs 4 Pin Ceramic Terminal Backcan Diameter 9.67 in / 245.6 mm Backcan Height 3.25 in / 82.5 mm Coverage Angle (±6dB @ 2kHz) 120° Crossover Frequency 4.0 kHz Cutout Width/Diameter 10.5 in / 266.7 mm Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 5.1 and 5 Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 6.2dB and 7.0dB Frequency Response (± 10 dB) 65 Hz - 22 kHz Frequency Response (± 3 dB) 125 Hz - 20 kHz Grille Properties Standard-Flange, Friction-Fit, White, Paintable, Painted, Steel Low Frequency Voice Coil 1 in / 25.4 mm Low Pass Crossover 12 dB per octave 2nd order Max. Ceiling Thickness 1.6 in / 40.6 mm Max. Continuous Power RMS 50W Max. Program Power 100 W Minimum Impedance ( Ohms) 17.9 Minimum Ceiling Thickness 0.04 in / 0.9 mm Network Type: High Pass 6 dB per octave 1st order Nominal Impedance ( Ohms) 16 Tweeter Driver 1" Silk Dome Woofer Driver 6.5" Treated Fiber Cone w/ Cloth Surround Sensitivity dB @ 1W/1M 90 dB Sensitivity dB @ 2.83V/1M 90 dB Tap Selector Rotary Switch Transformer Options 25 / 70.7 / 100 V, 16 Ohm direct Transformer Taps (25V/70.0V/100V) 4W/32W/32W Visible Diameter 11.75 in / 298.5 mm Visible Height 0.34 in / 8.6 mm

“Includes original open box. Never installed.”

Type

Speaker

Brand

Soundtube

MPN

CM62-EZS-II-WH
