South Bend Lathe Instructions Sheet 1928-9 Inch Junior New Model

US $19.00

  • Delhi, New York, United States
  • Jan 30th
Open on mobile:
QR code
Rare South Bend Lathe item.  Catalog Supplement No.23-S,  titled "Application of the 9-inch Junior New Model South Bend Lathe in the Electrical Shop, Service Station and Auto Repair Shop", dated December 6, 1928 Four pages detailing methods of using this tool in those facilities, such as Making Bushings, Truing Commuters,  and a dozen other uses are shown. Also a page of "Equipment for Servicing Armatures, Valve Bushings and Pistons" shown & described.  Measures 8" X 10 1/2" Excellent condition
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “no defects”
