Sovik 2" 2 Inch Stroke Micro Linear Actuator,12v Dc Speed 0.63" Per Sec Built In

US $80.99

San Jose, CA, United States
Jul 7th

Open on mobile:
QR code

Store New Arrivals Add to Favorite View Feedback Contact SOViK 2" 2 inch Stroke Micro Linear Actuator,12V DC Speed 0.63" per sec Built in Description 2" stroke length, 8" retracted length(minimum mounting length), 9.84" extended length 44Lbs max load. No load speed: 0.63" per sec. Built in limit switch Innovatively in-line design, 6mm diameter mounting holes, come with a pair of mounting brackets High quality aluminum alloy material housing. Easy to install and use, lighter weight and smaller body Applicable to a variety of conditions, such as Throttle Control, Air Vent Opening, Remote Window Operation, Remote Mirror Positioning, Gate Opening, Shutter Control and so on Product Description Max Load 22 pounds 44 pounds 55 pounds No-load Travel Speed 1" per sec 7/11" per sec 8/25" per sec Retracted Length 8 inch / 200mm 8 inch / 200mm 8 inch / 200mm Extended Length 10 inch / 250mm 10 inch / 250mm 10 inch / 250mm Limit Switch ✓ ✓ ✓ Duty Cycle 25% 25% 25% Mounting Brackets ✓ ✓ ✓ Protection Class IP54 Rated IP54 Rated IP54 Rated Item Weight 0.8 pounds 0.8 pounds 0.8 pounds Dimension(Closed) 8.7"(L)x1.26"(W)x1"(H) 8.7"(L)x1.26"(W)x1"(H) 8.7"(L)x1.26"(W)x1"(H) SOViK 2" Stroke 12V DC Linear Actuator 22lbs, 44lbs, 55lbs Maximum Lift Includes Mounting Brackets Specifications Input Voltage: 12 DC Starting Current(No-load): 0.1A Max Current: 1.5A Mounting Length=Retracted Length(hole to hole): 8 inch/200mm Mounting Holes: 6mm diameter Main Material: Aluminum alloy Application and Features The item is suitable for various windows / shutters /gate which need to be opened and closed For the DIY lovers, their functions will be up to your imagenation. Item weight just only 0.8 pounds, you can hold it to anywhere without any burden. You can use it anywhere when you need an automatic linear motion. Get rid of bulky, get rid of changeless, just go for it! How to connect and use Prepare to connect the two wires of the actuator to a 12 volt battery Red wire to the positive terminal and black wire to negative terminal will make the actuator extend. To make it retract, just reverse the terminal connections If the actuator does't work when you first connect, don't worry, just exchange the connection locations of two wires To simplify the last step, you can prepare a reverse polarity switch for the actuator. When you want the actuator to extend and retract, just press the switch Your actuator will hold its position when the power is off. It will automatically stop when reaches the end, due to the limit switch is built in. How to prolong the service life of actuator Please use the 12V DC power adapter The actual load does not exceed the rated load All the actuators have duty cycle, they are unable to work all the time without stop. The duty cycle of this actuator is 25%. it means that your actuator needs 3 minutes to rest for every 1 minute of work. If the actuator keeps working for long time, the motor is easily burnt out. Use the lubricating oil properly (Original type of lubrican is Mobli XHP222 grease) Please be careful, the actuator not completely waterproof What you will get 1pc SOViK 2" Stroke Linear Actuator 1 set Mounting Brackets Mounting Brackets Application As opener for Air Vent Instead of door bolt for your gate Instead of manual window opener for your greenhouse As Opener for Shutter ABOUT US We offer the best prices around on high quality products. Our E-store includes media such as books, movies, music and games while offering electronics, toys, sporting apparel, clothing, tools, general home, garden items and more. SHIPPING We are always working hard to ensure your package arrives as soon as possible. Please understand that some factors like weather, high postal traffic, and the performance of shipping companies are outside of our control. We offer free shipping to the lower 48 states and ship within 2 business days of payment, usually sooner. We do not accept P.O. Boxes. Please provide a physical address. For shipping outside of the continental USA, we only use eBay's Global Shipping Program.The item is shipped to KY and then sent to the rest of the world. International customers are responsible for all duties and taxes. Continue to check out in order to calculate costs for shipping the item to your country. Messages regarding eBay's Global Shipping Program MUST be directed at eBay EXCLUSIVELY. RETURNS We offer a 30-Day Return Policy on items which you are not completely satisfied with. You have the option for a full-refund or an exchange of the item. No returns are available on items shipped outside of the USA. PAYMENT We accept PayPal. CONTACT US This page content is yet to come Please ad us to your favorite seller and visit again later Thank You CUSTOMER SATISFACTION We try our very best to make sure every customer is completely satisfied. If there's a problem, message us! We're happy to help. WE ACCEPT Copyright © 2017 AutoDs. | All Rights Reserved

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Color	Does Not Apply
EAN	0711181883213
Manufacturer	SOViK
MPN	Does Not Apply
Model	S100-50-12-20
Style	Full load:20kgs
Brand	SOViK
item_width	1.22
UPC	711181128987
item_length	1.07
ISBN	Does not apply
