SparkFun Clock Generator Breakout 5P49V60 (Qwiic), US $29.95 – Picture 0
SparkFun Clock Generator Breakout 5P49V60 (Qwiic), US $29.95 – Picture 0

Sparkfun Clock Generator Breakout 5p49v60 (qwiic)

US $29.95

  • Swanton, Vermont, United States
  • Jul 16th
Open on mobile:
QR code
Description SparkFun Clock Generator Breakout 5P49V60 (Qwiic) Offers a wide range of customizable frequencies Redundant clock inputs with manual switchover Programmable output enable or power-down mode Four clock outputs can generate frequencies from 1-200MHz No soldering required The SparkFun Clock Generator Breakout 5P49V60 (Qwiic) offers a wide range of customizable frequencies in a wide range of different signal types using a single reference clock. Four (single output) clock outputs can generate frequencies from 1MHz-200MHz and eight (differential output) clock outputs can generate frequencies from 1MHz-350MHz. The frequency's many properties can be manipulated in code via I2C using the SparkFun Arduino Library. There are two Qwiic connectors populated on the board to easily configure the clock generator without the need for soldering to the I2C lines. However, soldering is required to connect to the clock outputs. Note: An oscilloscope is highly recommended to verify that the programmed clock signal is correct as its the only way to verify the output accurately. Specifications I2C Serial Programmable Interface (Qwiic-enabled) Arduino Library to manipulate frequencies via I2C Two Selectable Addresses 0x6A (default) or 0x68 4x Single-ended clock outputs can generate frequencies from 1MHz-200MHz in the following signal output: LVCMOS 8x Differential clock outputs can generate frequencies from 1MHz-350MHz in the following differential outputs: LVDS LVPECL HCSL Operating temperature range -40°C to +105°C Operating voltage range 1.8V, 2.5V, 3.3V Typically 3.3V using the Qwiic cable What's Included 1 x SparkFun Clock Generator Breakout 5P49V60 (Qwiic) Multimedia
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Sparkfun Electronics
Type Sparkfun Electronics
MPN Does not apply
UPC Does not apply
