Sparkfun Mp3 Trigger

US $84

Temple City, California, United States
Oct 22nd

Open on mobile:
QR code

SparkFun MP3 Trigger Product Features Input Voltage Range: 4.5V to 12.0V DC, or regulated 3.3V (jumper selectable). Current Consumption: Approximately 45mA idle, 85mA playing Media: SDSC and SDHC microSD cards File system: FAT32 and FAT16 Audio output: Headphone stereo (1/8" stereo jack) Trigger inputs: Logic level 3.3V-5.0V, active low inputs, w/ internal pull-ups (connector provides individual grounds, allowing switches or jumpers to be connected directly to each trigger input) Serial: Full duplex, 8-bit, 38.4Kbaud (default, other baud rates supported via initialization file) Product Description Make some noise with your next project! The MP3 Trigger board is built to make MP3 sound integration easier than ever. The board has 18 external trigger pins that will directly trigger pre-selected MP3 tracks, and a full-duplex serial control port that provides full transport control, remote triggering for up to 256 tracks, and fast real-time volume control. MP3s are stored on FAT16 formatted SDSC or FAT32 formatted SDHC micro-SD flash memory cards. In addition, optimized code can achieve 192Kbps stereo playback from a wider range of cards. The heart of the MP3 Trigger board is the Cypress PSoC CY8C29466-24SXI microcontroller which serves up MP3 data to a VLSI VS1063 audio codec IC. This version also supports an optional initialization file that can be used to set the serial port baud rate as well as to reprogram any of the 18 trigger inputs to alternate functions, including random and sequential track selection, transport controls and even volume up/down. Each conventional trigger can be set to either allow immediate restarts, or to lock out restarts if audio is playing. Also, a new trigger filename convention provides greater flexibility in naming your MP3 tracks and makes file management easier. This version of the MP3 Trigger includes firmware that supports the use of an initialization file on the microSD card that can be used to change the serial baud rate, as well as to repurpose any of the 18 trigger inputs to alternate functions, such as random and sequential triggers, navigation controls and even volume controls. In addition, a restart lockout option can be used to prevent any trigger from starting a track if audio is already playing. Using these features, custom applications can often be implemented without the use of a separate microcontroller. Note: This product is a collaboration with Robertsonics. A portion of each sales goes back to them for product support and continued development. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ Shipping Terms: Shipping is ONLY to the 48 Contiguous US States.. This excludes these locations: Alaska, Hawaii and Puerto Rico. APO/FPO’s are definitely excluded. PO Boxes: Please include a physical street address. Many items cannot be shipped to a PO Box. Your order will be delayed if a physical address is not provided. Expedited shipping is available for most items. We will contact you within 24 hours if an item cannot be expedited. Terms of Sale and Feedback: Please leave us a good rating after you have received the item and are happy with our transaction. If there are any issues, please contact me first before leaving a neutral, negative or 5 star rating. Customer Satisfaction is our top priority!! We promise we can make you happy if you give us a fair chance. Thanks and happy bidding!! Returns: All items qualify for returns within 14 days of receipt. Please send a message through eBay if an item is damaged, broken, or incorrect so we can promptly track and resolve any issues. SALES TAX: In those States where State taxes must be collected there may be a separate invoice that follows the order and will be in a separate PayPal cover. The reason this is that the system is not programed for this is in all cases. Some of these States are but does not exclude others: Arizona, California, Kansas, New York, North Dakota, Pennsylvania, Texas and Washington. ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
