Sparkfun Thing Plus Stm32

US $31.45

Swanton, Vermont, United States
Jul 16th

Open on mobile:
QR code

Description SparkFun Thing Plus STM32 Offers 16MB of Flash and MicroSD slot for expandable memory Comes flashed with the DFU bootloader Features economical and easy to use development platform Qwiic Compatible Provides a 3.3 V regulator and LiPo charger The SparkFun Thing Plus STM32 provides you with an economical and easy-to-use development platform if you're needing more power with a minimal working space. The STM32 Thing Plus provides a 3.3V regulator and LiPo charger as well as 16MB of Flash and MicroSD slot for expandable memory. This Thing comes flashed with the DFU bootloader, and to make the Thing Plus even easier to use, a few pins have been moved around to make the board Feather compatible. In addition, it utilizes the handy Qwiic Connect System which means no soldering or shields are required to connect it to the rest of your system! Specifications 1 Mbyte of Flash memory 192 Kbytes of SRAM including 64 Kbytes of CCM (core coupled memory) data RAM Flexible static memory controller supporting Compact Flash, SRAM, PSRAM, NOR, and NAND memories ARM 32-bit Cortex-M4 CPU with FPU Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait state execution from Flash memory Frequency up to 168 MHz Memory protection unit 210 DMIPS/ 1.25 DMIPS/MHz (Dhrystone 2.1) DSP instructions Clock, reset, and supply management 1.8 to 3.6 V application supply and I/Os 32 kHz oscillator for RTC with calibration Internal 32 kHz RC with calibration Low-power operation Sleep, Stop and Standby modes VBAT supply for RTC, 20x32 bit backup registers + optional 4 KB backup SRAM Debug mode Serial wire debug (SWD) & JTAG interfaces Cortex-M4 Embedded Trace Macrocell Advanced connectivity USB 2.0 full-speed device/host/OTG controller with on-chip PHY USB 2.0 high-speed/full-speed device/host/OTG controller with dedicated DMA, on-chip full-speed PHY, and ULPI 10/100 Ethernet MAC with dedicated DMA: supports IEEE 1588v2 hardware, MII/RMII Specific Peripherals available on STM32 Thing Plus: UART bus I2C Bus SPI bus Up to 15 Analog Inputs, Two Analog Outputs 20 Digital I/O Pins, 14 PWM Capable SDIO for microSD card support JTAG Serial Wire Debug Support Power Select LiPo Charging Circuit 3.3 V Regulator 128 Mbit SPI Flash What's Included 1 x SparkFun Thing Plus STM32 Dimensions Size 2.3 x 0.9 inch (L x W) Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Sparkfun Electronics
Type	Sparkfun Electronics
MPN	DEV-17712
UPC	Does not apply
