Spectrum Analyzer Analyser 150khz To 500mhz -100dbm To +13dbm 110v-240v At5005

US $543.00

  • Shenzhen, China
  • Jan 29th
Open on mobile:
QR code
Features: Frequency Range : 150KHz to 500MHz 4 1/2 Digit Display : Centre & Marker Frequency, 0.1MHz Resolution Amplitude Range : -100dBm to +13dBm Filters : 20KHz, 250KHz & Video Filter. Output Power : +1dBm to -50dBm (50 ohms) Specifications: FREQUENCY Frequency range: 150 KHz to 500MHz (-3dB). Center Frequency ±100KHz Resolution of frequency display: Resolution 100KHz, ( 4 1/2 digit ) Marker Accuracy 0.1% Span +100KHz Frequency Stability (Drift) <150 KHz / hr Frequency Span Zero span 0Hz/div, and 100 KHz/div to 100MHz/div in 1-2-5 sequence. Accuracy ±10% RBW (-3dB) Resolution 20 KHz & 250KHz Video Bandwidth, VBW 400 KHz Sweep Time (Fixed) 23ms AMPLITUDE Amplitude Range -100dBm to +13dBm Screen Display Range 80dB (10dB/div)., 8 div Reference Level -27dBm to +13dBm (in 10dB steps), -27,-17,-7,+3 and +13dBm Accuracy (Ref. Level) ±2dB Average Noise Level -103dBm (25 0KHz RBW) Frequency Response(Relative to 250MHz, ATTN 10dB) ±2dB Inter-modulation (3rd order) (Spurious Response) <-75dBc (2 signals, -27dBm each, Freq. Distance >3MHz) Harmonic Distortion (2nd, 3rd): <-75dB Absolute Amplitude Accuracy ±2.5dB INPUT Input Impedance 50 ohms Input Connector BNC Input Attenuator 0 to 40 dB (4 x 10 dB steps) Input Attenuator Accuracy ±2dB / 10dB step Max. Input Level : +10dBm, (0dB attenuation), DC : ±25V AT5005 Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, UK, Italy, Japan, Korea, Malaysia, Thailand, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Model AT5005
Analyzer Type Spectrum Analyzers
MPN AT5005
Unit Type Complete Systems & Mainframes
Country of Manufacture China
Country/Region of Manufacture China
