Spicer Sc12 Ac/dc Stray Field Cancellation System Complete System

US $5,000.00

Laconia, New Hampshire, United States
Jan 30th

Open on mobile:
QR code

Hi, bidding on a working Spicer SC12 EMI Cancellation System. This is a complete working set. Has controller, AC sensor, and all X, Y, and Z cancellation coils. Complete and ready to go. To be used on scanning electron microscope SEM, Transmission Electron Microscope TEM and Focused Ion Beam systems FIB. Link to the Manual: http://www.mhzelectronics.com/ebay/manuals/spicer_consulting_sc12_magnetic_field_cancelling_system_manual.pdf Key Features: •AC Field Cancelling •50 milligaus Pk-Pk Range •0.5 Hz - 5 kHz AC Bandwidth •50 X Field Improvement Typically •Full 3 Axis System •DC Cancelling Option •Measures magnetic fields •1 microgauss resolution Description: The SC12 was introduced in 1996 to replace the original Spicer Consulting SC07 System. Hundreds of SC12 systems are in use, world-wide, protecting electron and focussed ion beam tools against magnetic fields. It is now being withdrawn in favour of the new SC22 cancelling system. This basic AC cancelling installation comprises the Magnetic Field Control Unit, the X,Y and Z multicore cables and the magnetic field sensor. The system works by superimposing a cancelling field of the correct amplitude, phase and direction to null out the problem field. The SC12 magnetic field control unit contains amplifiers which drive currents through the cables to generate the cancelling field. The magnetic field sensor measures the field on X,Y & Z orthogonal axes in real time, then the measured signals are amplified and fed back in anti-phase to the power amplifiers. Hence the system is closed loop and the negative feedback nulls the field at the sensor location. The SC12 includes an accurate magnetic field measuring capability with a 3.5 digit panel meter for display. The real time measured fields are also available as analog voltage levels for oscilloscope or chart recorder display. The basic SC12 can measure the true RMS amplitude of AC fields. When a DC sensor is added, the system can also measure incremental DC fields. The panel meter can be switched to display any of the axes. General Specifications: Coordinate System: X, Y, Z rectangular Cartesian Units: Gauss, Tesla (switchable) Power Requirements: 120 V, 60 Hz or 240 V 50 Hz, 50 A Field Cancelling Specifications: Standard SC12 System: Components Cancelled: X, Y, Z field components Dynamic Range: 50 milliGauss pk-pk per axis Field Reduction Ratio: 50X (typical) at 50/60 Hz Bandwidth: 0.5 Hz - 5000 Hz Detector Noise Limit: 0.002 milliGauss pk-pk Wideband DC Sensor Option: Components Cancelled: X, Y, Z field components Ambient DC Field: 2 Gauss, Max Dynamic Range: 40 milliGauss pk-pk per axis Field Reduction Rate: 50X (typical) at 50/60 Hz, 50X (typical) at DC (incremental) Bandwidth: DC - 2.5 kHz Detector Noise Limit: DC: 30 µG Pk-Pk typ. (0.0001 - 0.01 Hz) AC: 1 µG/? RMS typ. at 50/60 Hz DC Drift: < 100 µG/24 hours Field Measurement Specifications: Types: 1: Real time field 2: AC - true RMS amplitude 3: Incremental DC (with DC sensor) Display: RMS & DC: 3.5 digit LCD panel meter Sensor Dynamic Range: 40 milliGauss pk-pk Meter Ranges: X1 Range: 0 - 1.999 mG RMS, ±1.999 mG DC (plus equivalent Tesla range) X10 Range: 0 - 19.99 mG RMS, ±19.99 mG DC (plus equivalent Tesla ranges) X100 Range: 0 - 199.9 mG RMS, ±199.9 mG DC (plus equivalent Tesla ranges) Accuracy: RMS: ±1.0% of reading +/0.003 mG Incremental DC: ±5% (after >1 hour warm up) Real Time Field Monitor: Signals: X, Y, Z real time fields Scaling: 500 mV/mg Range: ±10 Volts Source Resistance: 10 K Connectors: 3 X BNC Bandwidth: With AC Sensor: 5 Hz - 20 kHz With DC Sensor: DC - 5 kHz Trip Range Adjustment: AC-RMS: 0 - 2.0 mG DC: 0 - 5.0 mG

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“tested fully functional”
