Square D Surgelogic 208/120v 120ka Tvs2ema12a 3-phase Surge Protector

US $240

Beaverton, Oregon, United States
Nov 7th

Open on mobile:
QR code

More surge protection than you will ever need. This unit sells for over $1,000. It has just been under the bench in the garage for years - new and never installed. It's yours for a fraction of what it is worth. Surge Suppressor, Service Voltage, 120kA/PH, 3PH/4W, 120/208VAC, NEMA 3R/12, EMA Mfr. Part#: TVS2EMA12A Current, Surge : 120 kA Enclosure Rating : NEMA 3R/12 For Use With : Industrial Equipment Mounting Type : Panel Mount Supply Voltage : 120/208 VAC Type : EMA Voltage, Operating : 120/208 V Overview The Surgelogic® EMA Series surge protective device is a modular parallel transient voltage surge suppressor (TVSS). The EMA device has multi-stage suppression circuits consisting of field-proven, fast-acting metal oxide varistors (MOVs). A surge suppression path is provided for each mode, line-to-neutral (L-N), line-to-line (L-L), line-to-ground (L-G), and neutral-to-ground (N-G). Each surge suppression mode is individually fused and uses circuitry with thermal cutouts to isolate the TVSS and ensure shutdown in the event of MOV damage during severe overvoltages, even when operated on high-fault current power systems. The suppression elements are encapsulated in a UL® Recognized potting material, another performance element that provides additional protection. A filter provides EMI / RFI noise attenuation. On-line diagnostics continuously monitor the device status, and LEDs signal a loss of a suppression circuit. An audible alarm with an enable/disable feature and dry contacts are included in the standard diagnostic package. Features External Mounting Next to Panelboards, Switchboards, Switchgear, or Motor Control Centers (MCCs) Individually Fused Suppression Modes Thermal Cutout Copper Bus Bar Construction Solid State Bi-Directional Push-to-Test On-Line Diagnostic Display Front Panel Alarm with Enable/Disable Switch LED Indicators Indicate Loss of Protection, or Fully Operational Circuit High-Energy Parallel Design for ANSI/IEEE C62.41 and C62.45 Category B and C3 Applications Duty Cycle Tested (ANSI C62.41 C3, 10 kA, 20 kV) Minimum 5000 Impulses Specifications Standard Internal 200 kA Surge Rated Fusing, 200 kA Short Circuit Current Rating Listed to UL1449 (Second Edition) and UL1283 Meets ANSI/IEEE C62.41 and C62.45, and UL Category Section 37.3 NEMA Ratings: 1, 3R and 12 (Outdoor) Short Circuit Current Rating: 200 kA EMI / RFI Filtering Up to -30 dB (100 kHz to 100 MHz)
