Square Wave 50hz-6khz Pulse Generator Module 200ma Dc 5-15v Frequency Adjustable

US $598

shenzhen, China
Oct 20th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Power Module Wireless Modules Sensor DIY LED Board Development Board Function Modules Digital Voltmeter Description Square Wave 50Hz-6KHz Pulse Generator Module 200mA DC 5-15V Frequency Adjustable Product Introduction: 1.Power Voltage:DC 5-15V;no load operating current 2.5MA(5V);no load operating current 6.5MA(12V) 2.Output Driving Current:200MA MAX 3.Applications:as signal source 4.Size:13*10*8mm(not include pin);pin space 2.54mm Functions: 1.After adding power,output port will output square signal,and amplitude is equal to power voltage 2.Output duty cycle cannot adjusted,and output siganl duty cycle is basically stable during adjusting freuquency (58%) 3.Frequency can be adjusted by multi-coil potenitometer:50Hz~6kHz 4.V1 port is uesd to control module start/stop vibrating Using Method: 1.Connect with power,and then it can operate 2.When V1 port is high level or hanging,module start vibrating output signal;V1 port connects with ground,module will stop vibrating,and output is low level 3.When using,0.1uf power filter capacitor can be connected with power to make sure stable operation 4.Clockwise adjust potentiometer,frequency will increase;anti-clockwise adjust potentiometer,frequency will decrease Pin Definition: 1.VCC:power 2.Vo:signal output port 3.Vi:start /stop vibrating control port 4.GND:ground Shippment Payment Return Policy Feedback About us We will arrange shipping for you within 24 Hours after payment cleared except the holidays. We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address you would like us to ship to. If not, please let us know before we sent you the package, or we will not be responsible for any loss. hope you could understand. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. We accept Paypal ONLY. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. * We believe our items are so outstanding. We are convinced you will be happy with your Purchase. * If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund to you after the returned item arrived at our warehouse. * Please include your eBay ID and item number with any email requests. * When you satisfied with our product and services please leave us positive feedback. * If you have got the package, please confirm "Delivery on time" For us. * If a problem occurs, contact us immediately with any email request. * Just contact us using the " Ask the seller a question" link on eBay. We mainly sell Modules, IC Acccesories, Home Gadgets, and outdoor products. Almost all products you need, You can get a best price once you send us the ebay message. For bulk order or wholesale, we promise to offer you a very competitive price! We welcome do more pleasant business with you. SKYPE: ada-yu2013 inkfrog terapeak inkFrog Analytics On Oct-19-16 at 20:48:20 PDT, seller added the following information:On Oct-19-16 at 20:48:38 PDT, seller added the following information:
