St Microelectronics Lf50abdt-tr Very Low Drop Voltage Regulator Dpak Omb2-26e

US $6.60

Caerphilly, Caerphilly, United Kingdom
Jul 6th

Open on mobile:
QR code

ST Microelectronics LF50ABDT-TR LF50ABDT-TR, LDO Regulator, 500mA, 5 V, ±1% 3-Pin, DPAK Very low drop voltage regulator with inhibit function Package - DPAK Reel Dated GK1121CW Sold as a multi choice re quantity, see drop down box above. 5, 10, 25 or 50 Pieces - the more you buy the greater the discount. Specifications Attribute Value Output Voltage 5 V Output Type Fixed Package Type DPAK Maximum Output Current 500mA Mounting Type Surface Mount Maximum Input Voltage 16 V Pin Count 3 Number of Outputs 1 Polarity Positive Quiescent Current 0.5mA Accuracy ±1% Minimum Operating Temperature -40 °C Maximum Operating Temperature +125 °C Length 6.6mm Line Regulation 25 mV Width 6.2mm Height 2.4mm Enable Yes Load Regulation 25 mV Dimensions 6.6 x 6.2 x 2.4mm Features Very low-dropout voltage (0.45 V) Very low quiescent current (typ. 50 µA in OFF mode, 500 µA in ON mode) Output current up to 500 mA Logic-controlled electronic shutdown Output voltages of 1.5; 1.8; 2.5; 3.3; 4.7; 5; 6; 8; 8.5; 9; 12 V Automotive grade product: 1.8 V, 2.5 V, 3.3 V, 5.0 V, 8.0 V, 8.5 V VOUT in DPAK and PPAK packages Internal current and thermal limit Only 2.2 µF for stability Available here in ±1% (AB) Supply voltage rejection: 80 db (typ.) Temperature range: from -40 to 125 °C They are stored with us still on original STM reel and are absolutely 'as new'. Originally supplied to a large 'Milspec ' type Co. these came to us as part of a lot of surplus stock, having been in storage for some years, reel dated 1121, we have classified them as 'new other'. For datasheet copy and paste:- https://www.st.com/resource/en/datasheet/cd00000546.pdf Sold as a multi choice re quantity, see drop down box above. 5, 10, 25 or 50 Pieces - the more you buy the greater the discount. Very low quiescent current (typ. 50 µA in OFF mode, 500 µA in ON mode) Output current up to 500 mA Logic-controlled electronic shutdown Output voltages of 1.5; 1.8; 2.5; 3.3; 4.7; 5; 6; 8; 8.5; 9; 12 V Automotive grade product: 1.8 V, 2.5 V, 3.3 V, 5.0 V, 8.0 V, 8.5 V VOUT in DPAK and PPAK packages They are stored with us still on original STM reel and are absolutely 'as new'. Originally supplied to a large 'Milspec ' type Co. these came to us as part of a lot of surplus stock, having been in storage for some years, reel dated 1121, we have classified them as 'new other'. For datasheet copy and paste:- https://www.st.com/resource/en/datasheet/cd00

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	MPN	LF50ABDT-TR
UPC	Does not apply
Brand	ST Microelectronics
