St/moto 2n3700 1 A 80 V Through Hole Low Power Npn Silicon Transistor - To-18-3

US $1.95

Stanton, California, United States
Jul 20th

Open on mobile:
QR code

ST/MOTO 2N3700 1 A 80 V Through Hole Low Power NPN Silicon Transistor - TO-18-3 NEW OLD STOCK LOT 30895 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT INTERNAL JUNCTION CONFIGURATION NPN VOLTAGE RATING IN VOLTS PER CHARACTERISTIC 140.0 MAXIMUM COLLECTOR TO BASE VOLTAGE, DC AND 100.0 MAXIMUM COLLECTOR TO EMITTER VOLTAGE/STATIC/BASE OPEN AND 7.0 MAXIMUM EMITTER TO BASE VOLTAGE, DC CURRENT RATING PER CHARACTERISTIC 0.60 AMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 500.0 MILLIWATTS MAXIMUM COLLECTOR POWER DISSIPATION INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR JOINT ELECTRONIC DEVICE ENGINEERING COUNCIL/JEDEC/CASE OUTLINE DESIGNATION TO-18 MOUNTING METHOD TERMINAL TERMINAL LENGTH 0.500 INCHES MINIMUM TERMINAL CIRCLE DIAMETER 0.100 INCHES NOMINAL TERMINAL TYPE AND QUANTITY 3 UNINSULATED WIRE LEAD OVERALL LENGTH 0.210 INCHES MAXIMUM OVERALL DIAMETER 0.195 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE TEST DATA DOCUMENT 06481-932121 DRAWING

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Maximum Collector-Emitter Saturation Voltage	1.0 V
Transistor Category	Power Transistor
Mounting Style	Through-Hole
Maximum DC Collector Current	1 A
Maximum Base-Emitter Saturation Voltage	-2 V
Brand	ST/MOTOROLA
Number of Pins	3
Package/Case	TO-18
Type	NPN
