Stacoswitch Rugged Keyboard With Built-in Pointing Device & El Backlight Ps/2 †

US $11.99

Sarasota, Florida, United States
Jan 29th

Open on mobile:
QR code

Each sale is for one new StacoSwitch M778MSLN3 rugged keyboard assembly. This is not a finished keyboard. There is no back or cable/jack. Instead, the assembly is designed to be mounted through an opening in an operator panel. Features built-in joystick mouse emulation and dimmable EL backlight. These are super high quality. I'll bet they cost the original (government?) customer close to $200 each. These measure approximately 11" x 6" x 1". That makes them about the same size as a standard keyboard minus the usual cursor keys and numeric keypad. The easiest way to make these work with a PC is to purchase a cheap 'PS/2 keyboard+mouse to USB adapter' here on eBay. I saw several with BIN of $0.99. Cut off the PS/2 connectors and solder the wires to the pads on the assembly. You'll also need either a USB extension cable or splice in a longer cable on the PS/2 side. The keyboard and mouse were immediately recognized under Windows XP. You're not going to need any special drivers. If you still own a PC old enough to include PS/2 jacks, you could cut the cords off an old keyboard and/or mouse and solder to the assembly. If you want to interface to your own microcontroller, you can just run generic cable/wires. The mouse and keyboard are actually 2 separate isolated circuits. There's also an alternate connection via 1mm-pitch flexible ribbon socket. The embedded Atmel microcontrollers are FLASH-based, but I don't see any provision for in-circuit (re)programming. Advertisement for similar model These come packaged in individual boxes. If you agree to shipment without the original box, we can offer better prices on quantity 2 or 3. Quantity 2 [Make Offer] of $11 each Quantity 3 [Make Offer] of $10 each Quantity 4+ will have to be evaluated on a case-by-case basis Any other offers will be ignored. USA buyers pay a maximum of $7.99 shipping for items with † or ‡ in the title. Tips for accurate combined shipping

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	StacoSwitch
Weight	15.2 oz
MPN	M778MSLN3
